YUKON part description

Yukon 4340 Chrome-Moly axles provide up to 50% increased strength over stock axles for use in extreme performance applications with large tires and high horsepower. Yukon's 4340 axles are manufactured using the latest technologies and the highest quality materials to ensure high strength and long life. This kit comes with inner & outer axles for both left and right sides along with Dana U/joints. Limited Lifetime warranty covers manufacturing defects and axle breakage for as long as you own the vehicle. This warranty is not transferable to another party. "No Questions Asked" replacement for first warranty return, however Yukon reserves the right to either replace axle or refund original purchase price after the first warranty claim. Yukon (through Randy's ring & pinion) makes final determination on warranty considerations.

Product Description

Yukon Chromoly Front Axle Kit, JK Non-Rubicon Dana 30, 27/32 Spline, 7166 uJoint

Features & Benefits

  • Fits Dana 30 differential
  • Includes two 32 spline outer axles
  • Includes 27 spline, 34.5” long RH inner axle
  • Includes 27 spline, 18.8” long LH inner axle
  • Heavy duty 4340 chromoly construction
  • Includes 1350/7166 Series u-joints

Kit Contains (2) 27spl Inner Axles, (2) 32spl Outer Stubs, (2) 1350 Series U-Joints. LH Inner 18.8" Long RH Inner 34.5" Long

Product Attributes

Aap Selling Package Quantity Uom EA
Aap_uda_12 EA
Aap_uda_22 1
Inboard Spline Quantity 27
Shaft Material 4340 Nickel Chromoly Steel
Title Yukon Chromoly Front Axle Kit, JK Non-Rubicon Dana 30, 27/32 Spline, 7166 uJoint

Additional Information

Warranty Special Lifetime
Warranty Special UOM LF
Country of Origin (Primary) IN
Harmonized Tariff Code (Schedule B) 8708504110
Harmonized Tariff Code (HTS) 8708505100
NAFTA Preference Criterion Code B
UPC 00883584218227

Part Interchanges

Fits Vehicles

  • Jeep Wrangler (2007-2017)
