MOOG 338 Part Description
Manufacturer
Product Description
Greaseable Premium Universal Joint
Features & Benefits
- BUILT TO LAST -- Rugged design specifically engineered for fleets, off-highway and commercial vehicles
- STRONG AND DURABLE -- Bearing cups are cold-formed, case-hardened and precision ground for strength and durability
- KEEPS DIRT OUT -- Abrasion-resistant nitrile seals provide ideal grease retention and protection from under-vehicle contaminants
- GREASEABLE DESIGN -- Drilled and tapped grease fitting holes for easy servicing and cross trunnions with large grease reservoirs with radial grease channels for grease distribution
- INHIBITS PREMATURE WEAR -- Cross trunnions ground to a 15-25 RMS finish for a smooth surface free of microscopic grooves that can cause premature wear
- RELIABLE PERFORMANCE -- Internal anti-drainback valve integrated into thrust washer controls lubrication flow and prevents dry startup
- RIGOROUS TESTING -- Comprehensive testing throughout design and development processes by MOOG engineers for quality you can count on
Engineered for optimal performance, MOOG® universal joints are machined to meet or exceed original equipment standards.
Over 70 years of aftermarket engineering and product expertise has made MOOG® an industry leader in driveline quality and customer satisfaction.
- Greaseable - allows new grease to flush out contamination and moisture reducing corrosion and wear
- Needle bearings and snap rings from an original equipment supplier
- Nitrile rubber grease seals have compressed double lip design for protection from contaminants
- Durable and strong with consistent heat treatment for good bearing hardness ratios
- Bearing cups ground and slightly oversized to fit in a used drive shaft
- Cross forging shape and flash provide easier installation and high strength
Part Specifications
U-JOINT SPECIFICATIONS
| U-Joint Identification | 4 Grooved Round Bearings |
| Bearing Type A | Round Grooved |
| Bearing Diameter A - Inch | 0.938 |
| Bearing Diameter A - mm | 23.8 |
| Length Measurement A | Outside of Groove to Outside of Groove |
| Length A - Inch | 1.5 |
| Length A - mm | 38.1 |
| Bearing Type B | Round Grooved |
| Bearing Diameter B - Inch | 0.938 |
| Bearing Diameter B - mm | 23.8 |
| Length Measurement B | Outside of Groove to Outside of Groove |
| Length B - Inch | 1.5 |
| Length B - mm | 38.1 |
| OE Series | Spicer 1000 |
| Lubricateable | YES |
| Lube Fitting Location | Angled lube fitting in center of cross |
| Dimension Across Bearing Wing A - Inch | 1.69 |
| Dimension Across Bearing Wing A - mm | 42.9 |
| Dimension Across U-Joint A - Inch | 3.5 |
| Dimension Across U-Joint A - mm | 88.9 |
| Bearing Type Notes | Uses Delta Wing Bearings in place of Low Wing Bearings |
| Image | UJoint_4Grooved.tif |
MOOG 338 Specifications
Product Attributes
| Bearing Cap Axis 1 Diameter | 0.938 IN |
| Bearing Cap Axis 1 Diameter | 23.8 MM |
| Bearing Cap Axis 2 Diameter | 0.938 IN |
| Bearing Cap Axis 2 Diameter | 23.8 MM |
| Bearing Cap Type | 4 Grooved Round Bearings |
| Length Axis 1 | 1.381 IN |
| Length Axis 1 | 35.077 MM |
| Length Axis 2 | 1.381 IN |
| Length Axis 2 | 35.077 MM |
| Length Measurement A | Outside of Groove to Outside of Groove |
| Length Measurement B | Inside of Groove to Inside of Groove plus thickness of 2 Lock Rings |
| LUBE FITTING LOCATION | Angled lube fitting in center of cross |
| Greaseable | YES |
| OE Series | Spicer 1000 |
| U-Joint Identification | 4 Grooved Round Bearings |
| Part Description | Universal Joint |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | MX |
| Canadian Harmonizing Tariff Code | 8708991510 |
| Harmonized Tariff Code (Schedule B) | 8708996810 |
| Harmonized Tariff Code (HTS) | 8708996810 |
| UPC | 00080066606583 |
MOOG 338 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 45U2000 |
| AUTOPAR | A-170X |
| Autopar - Archived | 10170, 2100170, 5103X, 5110X, 5170X, G5170X, G5570X |
| BorgWarner | 114-570 |
| British Leyland | 510, 570, 571 |
| Chicago Rawhide | 1-0170, 28170X |
| DANA | 25-103X, 5-103X, 5-110X, 5-170X |
| GMB | 210-0170, G5-170X, G5-570X, 10170, 114570, 2100170 |
| General Motors | 89029412 |
| Mcquay-Norris | U170 |
| NEAPCO | 1-0170 |
| Neapco OE Series | 1-0170, 28170X |
| Perfect Circle | 103 |
| SKF | 1-0170, 28170X |
| Spicer | 5-103X, 5-110X, 5-170X, DT103, DT110, DT170 |
| TRW Steering and Suspension Parts | 20017 |
| WORLD AMERICAN | 5-170XR |
MOOG 338 Fits Vehicles
- Ford F-Super Duty (1988-1997)
