DANA SPICER 5-170X Part Description
Manufacturer
Product Description
Universal Joint Greaseable; Spicer 1000 Series PTO u-joint
| Brand: | Spicer |
| Greaseable: | Y |
| Type: | ISR Style |
| OEM Mfg: | Spicer |
| OEM Series: | 1000 |
| Bearing Cap Diameter (1): | 0.938 |
| Bearing Cap Diameter (2): | 0.938 |
| Snap Ring (1): | 1.5 |
| Snap Ring (2): | 1.5 |
| VMRS: | 24002046 |
| Package Type: | Each |
| Package Quantity: | 1 |
| Weight: | 0.6 lbs. |
| Country of Origin: | United States |
| UPC Code: | 023913126315 |
Dana Holding Corporation Spicer 1000 Series PTO U-Joint
The Dana Holding Corporation Spicer u-joint is crafted from high-quality materials to deliver best-in-class efficiency and outstanding durability. A part of the vehicle’s driveline, this u-joint helps restore the vehicle’s superior ride and handling.
Features & Benefits
- Manufactured to meet strict quality standards for guaranteed dependable performance
- Spicer products are designed to the same exacting standards as specified by OEMs
- Helps make the vehicle or truck operate at peak performance levels
- Backed by the company’s over 115 years of innovation and technological revolutions
- Fits a variety of applications from light-duty trucks to commercial and off-highway vehicles
| Series | 1000 |
DANA SPICER 5-170X Specifications
Product Attributes
| Material | Steel |
| Bearing Cap Diameter (1) | 0.938 IN |
| OEM Mfg | Spicer |
| OEM Series | 1000 |
| Type | ISR Style |
| Bearing Cap Diameter (2) | 0.938 IN |
| Bearing Cap Type | Round with ISR Groove |
| Snap Ring Included | Yes |
| Snap Ring Type | Internal |
| Grease Zerk Included | Yes |
| Pre Greased | No |
| Grease Fitting Location | Center of Cross |
| Greaseable | Yes |
| Bearing Cap Diameter A (mm) | 23.825 MM |
| Bearing Cap Diameter B (mm) | 23.825 MM |
| Bearing Cap Type A | ISR |
| Bearing Cap Type B | ISR |
| Hardware Included | No |
| Length A (In) | 1.500 IN |
| Length A (mm) | 38.100 MM |
| Length B (In) | 1.500 IN |
| Length B (mm) | 38.100 MM |
| Mounting Hardware Included | No |
| Distance Btw Snap Ring Grooves | 1.500 |
| Distance Btw Snap Ring Grooves (ISR) (2) | 1.500 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708996810 |
| UPC | 00023913126315 |
| VMRS Code | 024002046 |
DANA SPICER 5-170X Cross References
| Brand | Part Number |
|---|---|
| TT5-170, SP5170X | |
| ACDelco | 45U2003, 45U2004 |
| AGCO | AG605289 |
| Allied Eastern Corporation (AEC) | 2207-AS |
| Allison Transmission | 02404877 |
| Broderson | 33390008 |
| Cameco | 0270029643, 02729643 |
| Caterpillar | 177-6969 |
| Crane | 184R-5 |
| DANA | 25-170X |
| DANA SPICER | 15-170X |
| Daimler Truck North America | 859107, SP 5 170X, SP 5 170XHP |
| Dana Commercial Vehicle Service Parts | 201SJ36, 2104-5170X, 5-170X25, DT170 |
| Diamond | 859107 |
| Dresser | 00735-019-00 |
| Freightliner | 859107, SP 5 170X, SP 5 170XHP |
| GMB | 2100170 |
| GRADALL | 00012-781 |
| General Motors | 02404877 |
| Genuine | SPI5-170X |
| HD VALUE | HD5170X |
| International Harvester (IHC) | 208959R91, 5170X, D5170X, E5170X, SB5170X, SD5170X, ZFT5170X, ZJU5170X |
| John Deere | AT211316 |
| MERITOR | CP170X |
| MOOG | 338 |
| MOOG Chassis Products | 1500, 1501, 338 |
| Mack | 201SJ36, 2104-5170X, 2170-5170X |
| MasterPro | 1500, 1501 |
| McNeilus | 2CK621, 3336757 |
| Midwest | 5-170XR |
| Motor Coach Industries | 16A-3-105 |
| NAVISTAR | E5170X |
| NEAPCO | 1-0170 |
| NEWSTAR | S-7026 |
| Navistar | 208959R91, 5170X, 5-170X, D5170X, DS5170X, ETN5170X, SB5170X, SD5170X, SD5170X25, ZFT5170X, ZJU5170X |
| Neapco OE Series | 1-0170 |
| New Holland Agriculture | 208959R91 |
| New Holland Construction | 208959R91 |
| Optima Batteries | 28961300 |
| Ottawa | 90010391 |
| Paccar Parts | 336757, 5170X, 5-170X |
| Peterbilt | 2CK621, 2-CK-621, 2GK621, 3336757 |
| Precision | 1500, 1501 |
| Prevost | 19509331 |
| Rockwell International | CP 170X |
| SKF | 1-0170, UJ1500, UJ1501 |
| SVL | 15-170X |
| Steiger Tractor | 208959R91 |
| UAP | 5-170X |
| Universal Coach | 16A-3-105 |
| Volvo | 201SJ36, 2104-5170X, 859107, SHP5170X, SP 5170X |
| WORLD AMERICAN | 5-170XR |
| Workhorse | 5-170X |
