Parker Hannifin 782TC-16 - Hydraulic Constant Working Pressure Hose 5000 PSI – 782 Hose
- Part Number
- 782TC-16
- Manufacturer
- PARKER HANNIFIN
- Description
-
Hydraulic Constant Working Pressure Hose 5000 PSI – 782 Hose
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
PARKER HANNIFIN part description
Parker's 782 hose was designed to deliver consistency and reliability with a constant working pressure of 5000 PSI in all sizes.
- Parker's 782 hose was designed to deliver consistency and reliability with a constant working pressure of 5000 PSI in all sizes. The 782 hose is designed, built and tested to exceed SAE 100R13 performance specifications. Sizes range from ¾” to 1 ½” in diameter with different cover options available for various markets.
Markets:
• Transportation
• Military
• Construction
• Grounds & Building Maintenance
• Forestry
• Industrial
Features/Benefits:
• ToughCover or SuperTough cover options to prevent abrasion
• Synthetic rubber inner tube for wide fluid compatibility
• 5,000 PSI constant working pressure in all sizes
• MSHA accepted cover
Applications:
• Petroleum base hydraulic fluids and lubricating oils
Compatible Fittings:
• 78 series fittings
Product Specifcations
| Hose I.D. (size) | -16 |
| Hose I.D. (inch) | 1 |
| Hose I.D. (mm) | 25 |
| Hose I.D. (DN) | 25 |
| Hose O.D. (inch) | 1.52 |
| Hose O.D. (mm) | 39 |
| Maximum Working Pressure (psi) | 5000 |
| Maximum Working Pressure (Mpa) | 35,0 |
| Hose Inner Tube Material | Synthetic rubber |
| Material - Hose Reinforcement | Four or six spiral steel wire |
| Hose Cover Material | Synthetic rubber abrasion resistant, MSHA accepted |
| Minimum Bend Radius (inch) | 12 |
| Minimum Bend Radius (mm) | 300 |
| Weight (lbs/ft) | 1.48 |
| Weight (kg/m) | 2,20 |
| Minimum Working Temperature (F) | -40 |
| Maximum Working Temperature (F) | 257 |
| Minimum Working Temperature (C) | -40 |
| Maximum Working Temperature (C) | 125 |
| Industry Standards | SAE 100R13 / ISO 3862-1 TYPE R13 / EN 856 TYPE R13 |
| Compatible Fittings | 78 Series |
| Applications | Petroleum based hydraulic fluids and lubricating oils |
Parker Hannifin® is a global leader in motion and control technologies. Included in the world's Fortune 250 companies, Park Hannifin's products are vital not only to automobiles but also to almost everything that moves or needs control. These include all forms of transportation, manufacturing and processing raw materials, as well as infrastructure development and construction. Established in 1918, the Parker Appliance Company's evolution into Parker Hannifin Corporation demonstrates a legacy of innovation and Parker's tradition of excellence. Parker Hannifin's product portfolio includes solenoid valves, hydraulic fittings, pressure relief valves, hydraulic pumps, polyurethane tubing, thermal and power management products, and other parts for climate control, hydraulics, filtration, fluid and gas handling, pneumatics, sealing and shielding, and many other applications.
