CENTRIC 128.35154 Part Description
Manufacturer
Product Description
Centric Premium OE Style Drilled Brake Rotor
Features & Benefits
- Premium rotors feature 100% fully machined finishes including rotor hats. This extra process provides better rotor balance and creates a cleaner; more finished looking component
CENTRIC 128.35154 Specifications
Product Attributes
| Hat Id [cntrc] In | 7.291 |
| Misc Holes [cntrc] | 2 |
| Hat Id [cntrc] Mm | 185.200 |
| Vane Style [cntrc] | Pillar |
| Weight [cntrc] Kgs | 16.020 |
| OEM Vane Count [cntrc] | 108 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 35.300 |
| Product Grade [cntrc] | Premium |
| Stud/Lug Hole Diameter | 0.598 IN |
| Stud/Lug Hole Diameter | 15.200 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 112.400 MM |
| Mounting Bolt Hole Circle Diameter | 4.425 IN |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69.000 MM |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | X Drilled |
| ABS Tone Ring Included | No |
| Outside Diameter | 14.567 IN |
| Outside Diameter | 370.000 MM |
| Overall Height | 2.539 IN |
| Overall Height | 64.500 MM |
| Hat Finish | Coated |
| Nominal Thickness | 1.417 IN |
| Nominal Thickness | 36.000 MM |
| Discard Thickness | 1.339 IN |
| Discard Thickness | 34.000 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890533856 |
CENTRIC 128.35154 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 95869, 2224200272, 2224215100, 228.35154 |
CENTRIC 128.35154 Fits Vehicles
- Mercedes-Benz S450 (2018-2020)
- Mercedes-Benz Maybach S560 (2018-2020)
- Mercedes-Benz S560 (2018-2021)
- Mercedes-Benz S550 (2014-2017)
- Mercedes-Benz S550e (2015-2017)
- Mercedes-Benz Maybach S550 (2017)
- Mercedes-Benz Maybach S600 (2017)
- Mercedes-Benz Maybach S650 (2018-2019)
