(888) 312-8812 Login SignupCENTRIC 120.52002 Centric Premium Brake Rotor
Tap to view 5 more
*Representative image - actual part not displayed
$17349
Limited availability at this price!
In Stock
Get it by Thursday, Jun 18
CENTRIC 120.52002 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.52002 Specifications
Product Attributes
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] In | 6.421 |
| Weight [cntrc] Lbs | 28.400 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 163.100 |
| Weight [cntrc] Kgs | 12.880 |
| OEM Vane Count [cntrc] | 111 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.181 IN |
| Discard Thickness | 30.000 MM |
| Nominal Thickness | 32.000 MM |
| Nominal Thickness | 1.260 IN |
| Hat Finish | Painted |
| Overall Height | 70.700 MM |
| Overall Height | 2.783 IN |
| Outside Diameter | 354.900 MM |
| Outside Diameter | 13.972 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.764 IN |
| Center Hole Diameter | 70.200 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.654 IN |
| Stud/Lug Hole Diameter | 16.600 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890972952 |
CENTRIC 120.52002 Cross References
CENTRIC 120.52002 Fits Vehicles
- Tesla X (2017-2021)
- Tesla S (2012-2021)
