DELPHI FG0508 Fuel Pump Module Assembly

★★★★★ (0)

$356.49

Limited availability at this price!

In Stock

Get as soon as Wednesday, Nov 25
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

DELPHI FG0508 Part Description

Manufacturer

DELPHI

Product Description

Fuel Pump Module Assembly

Features & Benefits

  • Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
  • Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
  • Lower amperage draws less load on vehicle's electrical system
  • Part is validated, tested and matched to the right vehicle application
  • Always be sure to check and clean fuel tank to avoid unnecessary returns
  • Lower failure rates due to its innovative design and durability

DELPHI FG0508 Specifications

Product Attributes

Package ContentsFuel Pump Module Assembly w/Float Arm, Instruction Sheet
Item GradeStandard Replacement
System Pressure44 psi
Fuel Level Sender Assembly IncludedYes
Vapor Pressure SensorYes
Outlet Outside Diameter0.375 IN
Voltage12 2H
Fuel TypeGas
Regulator IncludedNo
Maximum Pressure109 PS
Terminal TypePin
Gasket Or Seal IncludedYes
Terminal Quantity3
Lock Ring IncludedNo
Terminal GenderMale
Strainer IncludedYes
Inlet TypeStrainer
Outlet TypeQuick Connect
Outlet Quantity2
In Tank or ExternalIn Tank
Resistance Ohms Empty290 82
Resistance Ohms Full80 82
Internal Or External StrainerInternal
Pump TypeElectric
Average Current Draw5 68
Average Flow Rating23 GPH
Fuel Sending Unit IncludedYes
Negative GroundNo
Mounting Hardware IncludedNo
Wire Quantity4
Grade TypePremium
Connector Quantity1
Connector ShapeOval
Housing MaterialPlastic
Installation WarningsNo
Connector GenderFemale
Fuel Filter IncludedNo
Gasket Or Seal MaterialNitrile Rubber
Minimum Pressure44 PS
Wire Harness IncludedYes
Pump DesignTurbine
Fuel Tank Pressure Sensor IncludedYes
Universal Or Specific FitSpecific

Additional Information

Harmonized Tariff Code (Schedule B)8413309000
Country of Origin (Primary)TH
Harmonized Tariff Code (HTS)8413309030
Warranty SpecialLimited
Warranty Special UOMLT
UPC00689604188910
VMRS Code044003258
UNSPSC25172409

DELPHI FG0508 Cross References

BrandPart Number
AirtexE8400M
AutoZoneDFG0508
Bosch67926
CARTER FUEL PUMPSP76555M
CarterP76555M
GMB540-2010
Import DirectA30335
Isuzu8-25330-132-1, 8-25333-229-1
N/A8253301321, 8253332291, USEP8400M, 4010184
Spectra PremiumSP4051M

DELPHI FG0508 Fits Vehicles

  • Isuzu Amigo (1998-2000)
  • Isuzu Rodeo Sport (2002-2003)
