(888) 312-8812 Login SignupCARTER FUEL PUMPS P76555M Fuel Pump Module Assembly
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CARTER FUEL PUMPS P76555M Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Carter Electric Fuel Pumps and Electric Fuel Pump Assemblies are made with all new materials under rigorous quality controlled manufacturing and testing procedures.
- Quality Carter Electric Fuel Pumps and Fuel Pump Assemblies deliver optimum performance while providing long life.
- Most applications include the necessary accessories such as tank seals, patented high-gradient density strainers and wiring harnesses.
- Fuel sensor design provides resistance to corrosive fuel blends and additives.
CARTER FUEL PUMPS P76555M Specifications
Product Attributes
| Fuel Sending Unit Included | Yes |
| Voltage | 12 2H |
| Terminal Type | Pin |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Shape | Oval |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Connector Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Fuel Filter Included | No |
| Inlet Fitting Thread Size | 3/8 IN |
| Minimum Pressure | 55.0 PS |
| Wire Harness Included | No |
| Outlet Fitting Thread Size | 5/16 IN |
| Minimum Flow Rating | 21 GPH |
| Pump Type | Electric |
| Minimum Flow Rating | 21.0 gph |
| 65000 | No Proposition 65 warning is required with this product. |
| Average Current Draw | 9 68 |
| Connector Color | Black/White |
| Connector Quantity | 3 |
| Fuel Type | Gas |
| Gasket Or Seal Material | Rubber |
| Height | 352 MM |
| Height | 13.86 IN |
| Inlet Fitting Thread Size | 3/8 |
| Internal or External | Internal External |
| Maximum Pressure | 123.28 PSI |
| Minimum Pressure | 51 PSI |
| Outlet Fitting Thread Size | 5/16 IN |
| Outlet Outside Diameter | 0.37 IN |
| Outlet Outside Diameter | 9.49 MM |
| Outlet Quantity | 1 |
Additional Information
| Country of Origin (Primary) | CN |
| Country of Origin 2 | MX |
| EAR99 | |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime Warranty |
| Warranty Special UOM | TX |
| UPC | 00889464081851 |
| VMRS Code | 044003258 |
| UNSPSC | 40151532 |
CARTER FUEL PUMPS P76555M Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 2920667 |
| AIRTEX | E8400M |
| AUTOBEST | F4411A |
| Airtex Fuel Pumps | E8400M |
| Carquest Premium Fuel Pumps | M3496293 |
| DELPHI | FG0508 |
| Delphi Fuel Pumps | FG0508 |
| GMB | 540-2010 |
| Import Direct Fuel Pumps | A30335 |
| Isuzu | 8-25330-132-1, 8-25330-132-0, 8-25166-153-0, 8-25166-815-0, 8-25318-882-0, 8-25319-101-0, 8-25321-567-0, 8253301321 |
| N/A | E8400M, FG0508, 2920667, 8-25166-153-0, 8-25166-815-0, 8-25318-882-0, 8-25319-101-0, 8-25321-567-0, 8-25330-132-0, 8-25330-132-1, 8253301321, A30335, C0536M, M3496293, SP4051M |
| NAPA Fuel Pumps | C0536M |
| Spectra Premium | SP4051M |
| TruGrade | B19112083TG |
CARTER FUEL PUMPS P76555M Fits Vehicles
- Isuzu Amigo (1998-2000)
