(888) 312-8812 Login SignupLETRIKA MS75 Starter 24V, 12T, CW, PLGR, Letrika/MAHLE AZG, 9kW, New
Tap to view 1 more
$940.00
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
LETRIKA MS75 Part Description
Manufacturer
Technical Data
| Product | Starter |
| Letrika P/N | IS1179 |
| Voltage | 24 V |
| Power | 9.0 kW |
| OEM P/N | 11.131.905 |
| MAHLE P/N | MS 75 |
| Description | AZG4687 |
| No. of pinion teeth | 12 |
| Module | 3.175 mm |
| Distance over two teeth | 15.68 mm |
| Outside diameter of pinion | 46.5 mm |
| Notes | Insulated ground |
| Nominal power is 6,5kW according to ISO 8856 | |
| Noseless version of starter | |
| Soft start relay | |
| With reduction gear |
| Letrika P/N | OEM P/N | MAHLE P/N | |
|---|---|---|---|
| IS1179 | 11.131.905 AZG4687 24V 9,0kW | MS 75 | Available |
| IS1179 | 11.131.481 AZG4643 24V 6,5kW | Superseded unit, see available P/N IS1179 |
Related Parts
| Letrika P/N | MAHLE P/N | DESCRIPTION | POS |
|---|---|---|---|
| 16.915.438 | MSX 1003 | Switch | 4 |
| 16.915.439 | MSX 1004 | Supplementary switch | 5 |
| 16.915.437 | MSX 1016 | Central cover | 3 |
| 16.915.261 | MSX 1047 | Stator | 12 |
| 16.915.263 | MSX 1049 | Set of brushes | 14 |
| 16.915.269 | MSX 1064 | Armature | 9 |
| 16.907.502 | MSX 1308 | Reduction gear | 8 |
| 16.915.440 | MSX 1402 | Brush holder | 13 |
| 16.907.862 | MSX 1417 | Drive end bracket | 1 |
| 16.915.874 | MSX 1484 | Pinion | 17 |
| 15.125.004 | MSX 1672 | Rear-end bracket | 15 |
| 16.908.340 | MSX 305 | Bearing | 10 |
| 16.907.488 | MSX 508 | Fixing set | 11 |
| 16.915.207 | MSX 560 | Lever | 7 |
LETRIKA MS75 Cross References
| Brand | Part Number |
|---|---|
| IS1179, MS 75 | |
| CATERPILLAR | 0R 2186, 3A 1872, 3A 1872 H, 3P 0007, 3T 2371, 3T 2579, 3T 2764, 3T 4583, 3T 4586, 3T 6305, 4N 3181, 4N 7752, 6V 5227, 8N 2145, OR 2186 |
| CUMMINS | 3 011 895, 3 604 484 RX, 3 604 784 RX, 3 900 2661, 3 907 821, 3 910 646, 3 938 502, 3604484RX, 3907821 |
| DELCO REMY | 10461025, 10461136, 10461533, 10478942, 1113827, 1113923, 1113928, 1113942, 1113950, 1113951, 1113959, 1113960, 1113967, 1113969, 1113982, 1113990, 1113992, 1113993, 1113998, 1114706, 1114711, 1114712, 1114729, 1114735, 1114740, 1114767, 1114776, 1114793, 1114805, 1114843, 1114845, 1114859, 1114860, 1114862, 1114863, 1114864, 1114905, 1114910, 1114914, 1114917, 1114945, 1114949, 1114953, 1114968, 1114980, 1990204, 1990297, 1990343, 1990357, 1990359, 1990360, 1990364, 1990373, 1990412, 1990453, 1990455, 1990474, 1990497, 1993704, 1993796, 1993804, 1993815, 1993833, 1993929 |
| FIAT | 4816170 |
| FORD | F6 HT 110001 EA, F6 HZ 11002 EA |
| HELLA | 8EA 732 855-001, 8EA 738 258-001, US 863 |
| JOHN DEERE | RE28782 |
| KOMATSU | 121 95 20 H92, 121 95 21 H92, 121 95 26 H92, 122 15 92 H91, 124 32 15 H92, 674 20 14 240, 690 64 4C 91, R674 20 14 240, STR 1016, STR 1019 |
| LESTER | 17402, 18005, 18020, 18021, 3370, 3710, 3948, 3955, 4746, 4987, 5601, 6226, 6232, 6355, 6361, 6369, 6544, 6779, 6780 |
| MITSUBISHI | M7T03774, M7T03777 |
| SCANIA | 571468 |
| VOLVO | 11030394, 3595446 |
| WILSON | 91-01-4158 |
