Leece Neville M110R2603SE2D - Starter Motor - PowerPro™ 7 Series, 7 Kilowatt Rating, M110 12 Voltage, with OCP
- Part Number
- M110R2603SE2D
- Manufacturer
- LEECE NEVILLE
- Description
-
Starter Motor - PowerPro™ 7 Series, 7 Kilowatt Rating, M110 12 Voltage, with OCP
details
$55349
MSRP: $837.97
Save: $284.48
Limited Availability
. Learn more
LEECE NEVILLE part description
Product Specifications
| Spec | Value |
|---|---|
| Item number | M110R2603SE2D |
| Sales number | M110603 |
| Series number | M110 |
| Notes | SAME AS M110R2603SE EXCEPT CHANGED FLANGE ANGLE TO 82.5 DEGREES AND THE IMS RELAY POSITION. |
| System voltage | 12 |
| kW | 7 |
| Dimensions in | MILLIMETERS |
| Rotation | CLOCKWISE |
| Housing coating | PAINTED |
| UL Approved | No |
| Pinion teeth | 11 |
| Pinion pitch | 6/8 |
| Pinion OD | 66.5 |
| Pinion at rest | 47.5 |
| Span over 2 teeth | 20.58-20.68 |
| Flange type | SAE J542 Type 3 |
| Flange image | |
| Switch position | 82.5° |
| Helper Relay | -45 |
| Ignition terminal | M5 |
| Battery terminal | M12X1.75 |
| Ground terminal | M12X1.75 |
| Wetclutch | Yes |
| Overcrank Protection | Yes |
| Volts | 12 |
A division of Prestolite Electric Incorporated, Leece-Neville® is a well-known supplier of starters, alternators, and other electrical equipment for transportation, industrial, and military applications. This brand shares the same "Easy to do Business" philosophy with Prestolite and the same manufacturing and distribution centers in America, Europe, Canada, China, Hong Kong, and Mexico. With an industry history that dates back to 1919, Leece-Neville has its glory days in the production of electrical starters, voltage regulators, and generators for trucks, airplanes, as well as industrial and marine equipment during the World War II. In July 1987, Leece-Neville was acquired by Prestolite Electric, which widened its reach to the international market and made the Leece-Neville name globally recognized.
