(888) 312-8812 Login SignupBENDIX K095020 Air Dryer
$1,63199
7 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
BENDIX K095020 Part Description
BENDIX K095020 Specifications
Product Attributes
| Air Dryer Type | Stand-Alone |
| AUX 1 Delivery Opening Pressure | 112 PSI |
| AUX 1 Delivery Port 1 | 1/4-18 NPT |
| AUX 1 Delivery Port 2 | 1/4-18 NPT |
| AUX 1 Delivery Port 3 | 1/4-18 NPT |
| AUX 1 Delivery Port 4 | 1/4-18 NPT |
| AUX 2 Delivery Opening Pressure | 103 PSI |
| AUX 2 Delivery Port | 1/4-18 NPT |
| Cartridge Thread | M39 x 1.5-6H RH |
| Cartridge Type | Standard |
| Cautionary Note(s) | Not applicable to this part |
| Clearance to Remove Cartridge | 1.00 IN |
| Compressor Unloader Port | Not applicable to this part |
| Cut-In Pressure | Not applicable to this part |
| Cut-Out Pressure | 9.6 BAR |
| Governor Included | Yes |
| Governor Reservoir Port | 1/8-27 NPT (with Schrader Valve) |
| Governor Type | Adjustable |
| Governor Unloader Port | 1/8-27 NPT (Plugged) |
| Heater / Thermostat Rating | 24V / 90W |
| Heater Connector Color | Gray |
| Heater Connector Type | Metri-Pack 280 Series 2-Way Sealed Connector (Male) |
| Market Indicator | Aftermarket New |
| Maximum Inlet Temperature | 160 AdegF (71 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | Mounting Defined by Customer |
| Number of Compartments | 2 |
| Pressure Protection Valve Configuration | 4 in Parallel |
| Pressure Range | 0.8 BAR |
| PRI Delivery Opening Pressure | 112 PSI |
| PRI Delivery Port 21 | 1/4-18 NPT |
| Purge Exhaust Port | Standard (with Adapter) |
| Purge Valve Type | DLU (Hard Seat) |
| Purge Volume | Standard |
| Remote Charge / Fill Port (through Desiccant) | Not applicable to this part |
| Remote Charge / Fill Port 1 (after Desiccant) | Not applicable to this part |
| Remote Charge / Fill Port 2 (after Desiccant) | Not applicable to this part |
| Reservoir Diameter | A~ 9.0 IN |
| Reservoir Fill Type | External Fill |
| Reservoir Length | 38.85 IN |
| Reservoir Material | Steel |
| Safety Valve Opening Pressure | 153 PSI |
| SEC Delivery Opening Pressure | 103 PSI |
| SEC Delivery Port 22 | 1/4-18 NPT |
| Supply Port | 1/2-14 NPT |
| VMRS Code 2 | 013-010-495 |
| VMRS Description 2 | Tank - Purge, Air Dryer |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078193440 |
| VMRS Code | 013010052 |
BENDIX K095020 Cross References
| Brand | Part Number |
|---|---|
| N/A | 5008972 |
