Horton 79A9998 - Engine Cooling Fan Clutch
$1,26399
MSRP: $1,612.26
Save: $348.27
Limited Availability
Pay over 3-12 months with
. Learn more
. Learn more
HORTON part description
Product Description
Engine Cooling Fan Clutch
Application Summary
AUTOCAR
Features & Benefits
- Built to the same specifications as Horton Genuine models
- Easy-to-install, exact drop-in replacements
- Total cost can be less than rebuilding
- Two-year warranty for line-haul applications
- Credit for old Horton or competitor cores
- Low eddy-current speeds reduce noise, increase available horsepower, conserve fuel and minimize radiator abrasion
- Higher, spring-actuated fan speeds make sure necessary cooling is delivered
- Faster engine warm-ups in cold weather
- Premium bearings and friction liners
- High torque for turning large fans
- Lower parts count for easy installation and maintenance
Two-speed fan clutch, fan clutch, engine cooling, fan drive, performance, cooling system, horsepower, performance, reman
Product Attributes
| BACK PULLEY DIAMETER | 7.77 IN |
| BELT CONFIGURATION | 8K |
| Belt Groove Location | 5.55 IN |
| BOLT CIRCLE | 6 IN |
| Center of JB To Top Right Mounting Hole | 0.21 IN |
| Fan Blade Stud Length | 1.1 IN |
| FAN PILOT DIAMETER | 5 IN |
| Heavy Duty | TRUE |
| HORIZONTAL MOUNTING DISTANCE | 3.58 IN |
| Overall Length | 8.14 IN |
| Stud Thread Size | .312-18 UNC-2A IN |
| VERTICAL MOUNTING DISTANCE | 2.76 IN |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8483604040 |
| Harmonized Tariff Code (HTS) | 8483604040 |
| NAFTA Preference Criterion Code | B |
| OEM's Part Number | 98A9998 |
| Warranty Distance | 300000 |
| Warranty Distance UOM | DH |
| Warranty Special | 7500 Hours |
| Warranty Special UOM | TX |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| VMRS Code | 042003131 |
Part Interchanges
HORTON 79A9998 Cross Reference
We have 6 alternatives for the 79A9998 by HORTON:
