(888) 312-8812 Login SignupBALDWIN PA2453XP Engine Air Filter - Extreme Performance Axial Seal Element for Various Applications
$39649
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
BALDWIN PA2453XP Part Description
Manufacturer
Product Description
Outer Air Element with Bail Handle
Application Summary
Case, Cat, KW-Dart, Terex, WABCO Equip
Outer Air Element with Bail Handle
BALDWIN PA2453XP Specifications
Product Attributes
| Outside Diameter 1 (mm) | 447.7 |
| Outside Diameter 2 | 18 5/16 |
| Outside Diameter 2 (mm) | 465.1 |
| Related to | {LL2453} (Long-Life Media Version);{PA2453} (Standard Media Version) |
| Remark 1 | Boot |
| Height | 23.53125 |
| Remark 2 | & |
| Replaces | Caterpillar 1W3637; Driltech 103653; Euclid 9038350; Komatsu 581-021-2120; WABCO VJ5175 |
| Use With | {PA2364}, {PA2454} |
| Inside Diameter 2 (mm) | 308 |
| Inside Diameter 2 | 12.125 |
| Inside Diameter 1 (mm) | 23.8 |
| Inside Diameter 1 | 15/16 |
| Height (mm) | 597.7 |
| Furnished Gasket | [1] Included |
| Fits | Case, Caterpillar, Driltech, KW-Dart, Terex, WABCO Equipment; Euclid, Komatsu Trucks |
| Attached Gasket | [2] Attached |
| Outside Diameter 1 | 17.625 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421310000 |
| UPC | 00791440090583 |
BALDWIN PA2453XP Cross References
| Brand | Part Number |
|---|---|
| BLDPA2453XP | |
| ACDELCO | A901C |
| AERZEN | 123520000 |
| AIR REFINER | ARM117782 |
| AMERICAN PARTS | 1150, 93238 |
| AP FILTERS | AP3520A |
| AP LOCKHEED | LK3520, AP3520, AP3520A |
| BALDWIN FILTERS | PA2453XP |
| BIG A FILTER | 93238, 1150 |
| BOMAG | 5821348 |
| BOWES | LAF1818 |
| BUCYRUS-ERIE | 46140255 |
| CANADIAN FILTER CO. | CFM574 |
| CARQUEST | 87238XP |
| CASE | P1050507, 1050507 |
| CATERPILLAR | 2430897, 3I0793, 1W3637, 1327172 |
| CONTINENTAL AG | PCA1570 |
| COOPERS | AZA514, AEM2022 |
| CUMMINS | 3638679 |
| CYCLONE | PMA117782 |
| DELUXE | AF684, 684 |
| DONALDSON | X009238, SRG290012, SRG200052, SRG200036, SRG200035, SRG200030, SRG200016, SRG200015, SRG200014, SRG200013, SRG200012, SRD580001, P185040, SMP181040, P181040, P142747, P140237, P136658, P129610, P129601, P117782, G290012, G200013, EAF5040, DBA7040 |
| DRILTECH | 103661, 103653 |
| EUCLID | 9059562, 9038350 |
| EUROFILTER | 3108 |
| FAUN FRISCH | 746713 |
| FILTER MEX | MFA1570 |
| FLEETGUARD | AF899NF, AF899M, AF899, AA2907 |
| FLEETLIFE | FA117782 |
| FLEETRITE | AFR8899, AAR82907 |
| FRAM | CA1570 |
| GFF | AF585310 |
| GLOBAL FILTERS | 62453 |
| GM GENERAL MOTORS | 9059562, 9059512, 9038350, 9016647, 25043064 |
| GONHER | GA569M, GA569E, GA569 |
| GRAINGER | 46T385, 2TCF2 |
| GUARDIAN FILTER CO. | G117782 |
| HEAVY DUTY AIR | TME7782, HDA7782, HDA6658, A6658, E7782 |
| INDUCONTROL | AR1570 |
| INGERSOLL RAND | 52277381, 35356153 |
| JOHN DEERE | AZ104110 |
| JURA (HIFI) | SA10849 |
| KENWORTH | 3040654, 3040653, 3040648, 3040644, 3040616, 3040615 |
| KNECHT | AG155 |
| KOMATSU | 5810212101, 5810212120 |
| KRALINATOR | LA574 |
| LETOURNEAU | VJ5175, VJ0075, VA0010, PB1400, 7001329, PB2101, PB1569 |
| LUBER-FINER | LAF7782, LAF1818, LAF1818MXM |
| MOTORCRAFT | FA756 |
| NAPA GOLD | 2238 |
| NELSON | 70125N, 117782 |
| NELSON-WINSLOW | 117782 |
| NU-TECH | S2787, N2787 |
| O&K ORENSTEIN & KOPPEL | 101094 |
| POCLAIN | 1050507, F1050507 |
| PUROLATOR | AF2922, A72922, 6696758 |
| QIF AIR | AP117782 |
| REFILCO | AF2238 |
| REYTOR | IT117782 |
| SAKURA | A9218 |
| SF-FILTER / SCHUPP | SL8946 |
| SURE FILTER TECHNOLOGY | SFA1040P |
| TEREX | 9038350 |
| UNIFLUX | XA277 |
| UNIT RIG | 901619, 22185 |
| UNITED AIR CLEANER | U17782 |
| UNITED ENGINE LIFE | U17782 |
| WABCO | VJ5175, VJ0075, PB2101, PB1400, PB1569 |
| WATSUN FILTERS | TK722 |
| WIRTGEN | 95383 |
| WIX | 42238 |
| WIX FILTERS | WIX FILTERS, 42238, 42238NP |
| WOODGATE | WGA406 |
