(888) 312-8812 Login SignupMELLING ENGINE PRODUCTS M254 M254 Stock Replacement : Standard Volume, Standard Pressure, Aluminum Oil Pump With Gasket
Tap to view 1 more
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MELLING ENGINE PRODUCTS M254 Part Description
Manufacturer
Product Description
Stock Replacement Oil Pump
Features & Benefits
- Precision engineered for optimum fit and function
- Manufactured from high quality materials for consistent durable wear
- Designed for long-life and worry-free performance
- Meets or exceeds original equipment specifications
MELLING ENGINE PRODUCTS M254 Specifications
Product Attributes
| Title | Engine Oil Pump |
| Width | 8.37 IN |
| Width | 213.0 MM |
| Height | 5.75 IN |
| Height | 146.0 MM |
| Grade Type | Standard Replacement |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 6 |
| Housing Material | Aluminum |
| Drive Type | Crankshaft |
| Oil Pump Type | Rotary |
| Pickup Screen Diameter | 0.53 IN |
| Pickup Screen Diameter | 14.0 MM |
| Mounting Hole Diameter | 0.315 IN |
| Mounting Hole Diameter | 8.0 MM |
| Oil Pump Pressure Type | Standard Pressure |
| Oil Pump Volume Type | Standard Volume |
| Pickup Screen Included | No |
| Intermediate Shaft Included | No |
| Inlet Size (in) | 0.500 |
| Inlet Size (mm) | 13.00 |
| Cover Material | Aluminum |
| O-Ring Included | Yes |
| Pump Cover Included | Yes |
| Shaft Material | Not Applicable |
| Timing Cover Included | No |
| Washers Included | No |
| Spacer Included | No |
| Gears Included | Not Applicable |
| Finish | Rust Preventative |
| Nylon Bushing Included | No |
| Guide Included | No |
| Governor Spinner Included | No |
| Cotter Pin Included | No |
| Bushing Included | No |
| Bolts Included | No |
| Rotor Material | Powdered Metal |
| Pickup Tube Diameter | 0.500 IN |
| Pickup Tube Diameter | 13.00 MM |
| Adjustable Bypass Pressure | No |
| Alternate Pressure Springs Included | No |
| Drive Shaft Included | No |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8413309060 |
| UPC | 00729295103141 |
MELLING ENGINE PRODUCTS M254 Cross References
| Brand | Part Number |
|---|---|
| AISIN | OPT-031 |
| Elgin | EM-254 |
| Enginetech | N/A |
| General Motors | 94846081 |
| ITM Engine Components | 057-680 |
| MAHLE | N/A |
| MELLING ENGINE PRODUCTS | M254 |
| Melling | M254 |
| N/A | OP915 |
| Rock Products | OP915 |
| Safety Auto Parts Corp | N/A |
| Sealed Power | N/A |
| Topline | OPTO18 |
| Toyota | 15100-15020 |
MELLING ENGINE PRODUCTS M254 Fits Vehicles
- Chevrolet Nova (1985-1988)
- Toyota Corolla (1984-1987)
