(888) 312-8812 Login SignupGATES 85799 Global G2XH 2-Wire Braid Xtreme Heat Hose - SAE 100R2 Type S
$632.85
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 85799 Part Description
Manufacturer
Product Description
Global G2XH 2-Wire Braid Xtreme Heat Hose - SAE 100R2 Type S
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp Couplings [G25 Series] and Stainless Steel Braid Couplings [G17 Series]
- Blue, oil- and abrasion-resistant, thin synthetic rubber cover indicates higher temperature hose
- Tested to industry-standard 600,000 impulse cycles
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: Petroleum-Based Fluids: -40 Deg. F to +300 Deg. F (-40 Deg. C to +149 Deg. C); Phosphate Esters Fluids: as recommended by the fluid manufacturers, but within a range of -40 Deg. F to +212 Deg. F (-40 Deg. C to 100 Deg. C)
GATES 85799 Specifications
Product Attributes
| Product Type | Global G2XH 2-Wire Braid Xtreme Heat Hose - SAE 100R2 Type S |
| Industrial Description | 6G2XHX50FT |
| Type | Hydraulic Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 5000 PS |
| Burst Pressure | 20000 PS |
| Temperature Rating | -40 Deg. F to +300 Deg. F (Petroleum-Base Fluid); -40 Deg. F to +212 Deg. F (Phosphate Ester Fluids) |
| Length | 50 FT |
| Dash Size | 6 |
| Inside Diameter | .375 IN |
| Outside Diameter | .74 IN |
| Bend Radius | 5 IN |
| Tube Description | Black, Oil & Chemical-Resistant, Synthetic Rubber |
| Hose Material | CPE - Type J |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Cover Material | Thin Synthetic Rubber - CSM - Type M |
| Cover Type | Oil, Abrasion & Flame Resistant |
| Cover Color | Blue |
| Coupling Recommendation | GlobalSpiral, MegaCrimp |
| SAE Standard | 100R2 |
| EN Standard | 853 2SN |
| ISO Standard | 1436 2SN R2 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | MX |
| Stock Status | N |
| UPC | 00770075257622 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
GATES 85799 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | FC195-06, GH195-6, GH195-06 |
| Dayco | 40006 |
| N/A | 04030038 |
| NAPA | 85799 |
