MONROE 5611 Part Description
Manufacturer
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 5611 Specifications
Product Attributes
| Compressed Length | 14.724 IN |
| Compressed Length | 374 MM |
| Extended Length | 22.992 in |
| Extended Length | 584 MM |
| Travel Length | 8.268 in |
| Travel Length | 210 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 1.5/16" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS42 |
| Upper Mount Type | Stem Mount - Stem Length X M10 Thread Pitch |
| Upper Mount Code | S1 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | BE17110722 |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | PL |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598007162 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5611 Cross References
| Brand | Part Number |
|---|---|
| 5611ST, GAMZ2V553AXRM1 | |
| Audi | 1K0513029HB, 1K0513029HE, 1K0513029HM, 1K0513029HN, 1K0513029HQ, 1T0413031CF, 1T0413031DB, 1T0413031DC, 1T0413031EL, 1T0413031KA, 1T0413031KB, 8J0513025A |
| Duralast | TS3334942B |
| FCS | 341620, 346374 |
| FCS AUTO PARTS | 341620 |
| GABRIEL | G51799 |
| KYB | 344459, 3430024, 743029, 343298, 349109, 343280 |
| KYB AMERICA LLC. | 344459 |
| MasterPro Shocks and Struts | VW106 |
| Monroe Shocks & Struts | 210056 |
| NAPA Shocks | 5611, 94396, NS5611 |
| OEM | 1K0513029HN, 1K0513029HT, 1K0513029MF, 1K0513029ME, 3C0513049CH, 1K0513029GP, 1K0513029HF, 1K0513029MG, 3C0513049CJ, 1K0513029HQ, 1K0513029HM, 1K0513029HJ, 1K0513029FT, 1K0513029HK |
| SENSEN | 32130330 |
| Top Quality | 785611 |
| UNITY AUTOMOTIVE | 257020, 2-257020-001, 4-11060-257020-001 |
| VAICO | V104248, V104250, V104256, V104254 |
| Volkswagen | 1J0413031BH, 1J0413031DQ, 1J0413031DR, 1J0513025DA, 1J0513025DG, 1J9513025A, 1J9513025E, 1K0513029FA, 1K0513029FB, 1K0513029FJ, 1K0513029FT, 1K0513029GP, 1K0513029HF, 1K0513029HJ, 1K0513029HK, 1K0513029HL, 1K0513029HT, 1K0513029ME, 1K0513029MF, 1K0513029MG, 1T0413031DH, 1T0413031DJ, 1T0413031EQ, 1T0413031GE, 1T0413031GG, 1T0413031GH, 1T0413031GJ, 1T0413031GK, 1T0413031HK, 1T0413031HM, 1T0413031HN, 1T0413031HP, 3C0413031AB, 3C0413031AC, 3C0413031AE, 3C0413031AH, 3C0413031AJ, 3C0413031AL, 3C0413031AS, 3C0413031AT, 3C0413031M, 3C0413031N, 3C0513049AR, 3C0513049AS, 3C0513049BD, 3C0513049BE, 3C0513049BF, 3C0513049BG, 3C0513049BH, 3C0513049BJ, 3C0513049BQ, 3C0513049BR, 3C0513049BS, 3C0513049CE, 3C0513049CH, 3C0513049CJ, 3C0513049CN, 3C0513049CP, 5C0413031AH, 5C0413031AK, 5C0413031BA, 5C0413031BD, 5C0413031DJ, 5C0413031M, 5C0513025H, 5C0513025J, 5C0513029AJ, 5C0513029E, 1K0513029HM, 1K0513029HN, 1K0513029HQ |
MONROE 5611 Fits Vehicles
- Audi A3 Quattro (2006-2013)
- Volkswagen Golf SportWagen (2010-2013)
- Volkswagen CC (2009-2017)
- Volkswagen Passat CC (2009-2012)
- Volkswagen Golf (2010-2014)
- Volkswagen Bora (2005-2010)
- Volkswagen GTI (2006-2014)
- Volkswagen R32 (2008)
- Volkswagen Rabbit (2006-2009)
- Volkswagen Passat (2006-2010)
- Audi A3 (2005-2013)
- Volkswagen Jetta (2005-2014)
