MONROE 58653 Part Description
Manufacturer
Product Description
Load Adjusting Suspension Shock Absorber and Coil Spring Assembly Pack of 2
Features & Benefits
- REDUCES SAG UNDER LOAD -- Ideal for occasionally hauling or towing varying loads; heavy gauge, calibrated coil spring reduces sag when loaded up to 1,200 lbs. (capacity limited by suspension, tires and transmission; see owner's manual)
- EXCEPTIONAL HANDLING -- Tuned specifically for each application, full-displaced valving automatically adjusts to road extremes to provide ride consistency
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and PTFE-banded piston helps reduce friction between the piston and pressure tube to enhance responsiveness to changing road surfaces
- LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while heavy-duty nitrocarburized rod delivers long life
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
MONROE 58653 Specifications
Product Attributes
| Lower Mount Code | LS27 |
| Upper Mount Code | LS27 |
| Includes Bump Stop | No |
| Hydraulic Lockout | No |
| Parts Pack(s) | None |
| Part Description | Shock Absorber and Coil Spring Assembly |
| Compressed Length | 18.94 IN |
| Dust Shield Included | No |
| Extended Length | 28.1 in |
| Internal Rebound Bumper | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.9/16" Sleeve OAL |
| Travel Length | 9.2 IN |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 39.69MM Sleeve OAL |
| Compressed Length | 481.1 MM |
| Extended Length | 714.8 MM |
| Travel Length | 9.2 in |
| Travel Length | 233.7 MM |
| Upper Mount Code | LS27 |
| Dust Shield Included | No |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Damping Type | Oil |
| Grade Type | Premium |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598137616 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 58653 Cross References
| Brand | Part Number |
|---|---|
| 58653ST, FV6Z14A630CAA | |
| FCS | SC00032 |
| Ford | 9L3Z18124BE, 9L3Z18124CE, 9L3Z18124DE, 9L3Z18124EE, 9L3Z18124FE, 9L3Z18124M, 9L3Z18125A, 9L3Z18125B, 9L3Z18125C, 9L3Z18125D, 9L3Z18125E, 9L3Z18125F, AL3Z18124A, AL3Z18124AA, AL3Z18124BA, AL3Z18124CA, AL3Z18124DA, AL3Z18124EA, AL3Z18124FA, AL3Z18124GA, AL3Z18124RB, AL3Z18124SB, AL3Z18124TA, AL3Z18125D, AL3Z18125E, AL3Z18125G, AL3Z18125H, AL3Z18125K, AL3Z18125L, BL3Z18124C, BL3Z18124F, BL3Z18124H, BL3Z18124J, BL3Z18125C, BL3Z18125F, BL3Z18125H, BL3Z18125J, BL3Z18125K, BL3Z18125L, CL3Z18124A, CL3Z18124B, EL3Z18124A, EL3Z18124B, EL3Z18124C, EL3Z18124D, EL3Z18124E, EL3Z18124F, EL3Z18124G, EL3Z18124H, EL3Z18124J, EL3Z18124K, EL3Z18124L |
| GABRIEL | G64079 |
| KYB | 554373 |
| NAPA Shocks | 58653 |
| UNITY AUTOMOTIVE | 252600 |
MONROE 58653 Fits Vehicles
- Ford F-150 (2009-2014)
