VELVAC 17970 Push-Lock Air Brake Fitting, Male Branch Swivel Tee, Brass, 1/4" x 1/8"

Item Overview:

• Designed for use with SAE J844 nylon tubing.
• DOT 49 CFR 571.106 compliant.
• Fittings comply with worldwide Standard and Legislation, including SAE J1131 "Hot Pull" requirements.
• Operating temperatures from -40° F to +212° F.
• Maximum operating pressure 0 to 150 psi.
• Elbows and male branch fittings with built in swivel for positioning.
• Collet with multiple teeth for high grip on the tube.
• Side load retention capabilities.
• Positive release bushing for easy insertion and removal of tubing.
• Thread sealant applied to all male pipe threads to reduce installation time and expense.

WARNING! Velvac's line of push-lock brake fittings and tubing are designed only for use in vehicles where air is utilized as the operating fluid. As such, Velvac's push-lock air brake fittings should only be used in a manner consistent with the manufacturer's specifications. Using Velvac's push-lock fittings or tubing improperly or in a manner inconsistent with the manufacturer's specifications may result in serious injury or property damage. For example, Velvac's push-lock fittings and tubing are not intended for use in environments exceeding 150 psi and temperatures below -40° and above +120° F. Velvac's push-lock fittings and tubing are intended for use only as defined in 49CFR571.106. The U.S. Department of Transportation prohibits the use of push-lock fittings and nylon tubing as a connection between a semi-tractor & trailer, or a drive shaft and chassis.

Specifications:
