WEATHERHEAD part description

Available Length (ft) 50
Burst Pressure (psi) 1000
Color See Note
Description Boston Easy Couple General Purpose Hose
Family Hose
General Application General purpose hose. Air and diesel fuel applications.
Government Specification MSHA
Hose Base Number H201
Inside Diameter (Fraction) 41706
Inside Diameter (in) 0.38
Min Bend Radius (in) 3
Outside Diameter (Fraction) 21/32
Outside Diameter (in) 0.65
Reinforcement Material 1 Fiber Braid

Features & Benefits

  • -40oC to 127oC (-40oF to 260oF)
  • Air, Water-40oC to + 100oC (-40oF to 212oF)
  • Sizes 4 through 16
  • 21 Bar (300 psi), [Size 16only is 14 Bar (200 psi]
  • Standard Colors are blue, black, green, yellow, gray, red
  • Extremely Flexible, Kink Resistant
  • Red, Green, Black and MSHA approved
  • Highest Quality General Purpose Hose, Air, Water, Fuel, Oil

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
