FEL-PRO 1188 Part Description
Manufacturer
Product Description
Engine Cylinder Head Gasket
Features & Benefits
- Fel-Pro Performance head gaskets accommodate the high cylinder pressures and cylinder head movement associated with performance engines.
- The latest development in Fel-Pro Performance head gasket technology is the PermaTorqueMLS (multi-layer steel) series.
- Strategically located sealing beads surround the combustion chamber and coolant passages concentrating clamp load to prevent leakage.
- Retains sealing integrity in engines that experience significant scrubbing and movement due to dissimilar materials (such as aluminum heads on a cast iron
- Not intended for use in emission controlled vehicles.
FEL-PRO 1188 Specifications
Product Attributes
| Material | PermaTorqueMLS multi-layer steel |
| Thickness | 0.039 IN |
| Grade Type | Performance |
| Cylinder Bore Diameter | 4.280 IN |
| Gasket Sealant Included | No |
| Application Notes | W9 heads - "A" aluminum block |
| Bore Size (in.) | 4.280 IN |
| Combustion Chamber Volume (cc) | 9.200 |
| Combustion Seal Design | MLS bore bead |
| Engine Displacement | 273, 318LA, 340, 360, P5, P7/R5, P8/R6, W7, W8, W9 |
| Engine Family | Chrysler V8 Racing Small Block, Chrysler V8 Small Block |
| Mfg. | Chrysler Performance |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8484100000 |
| Harmonized Tariff Code (Schedule B) | 8484100000 |
| Harmonized Tariff Code (HTS) | 8484100000 |
| UPC | 00614046876897 |
FEL-PRO 1188 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2907 |
| AutoZone | 206131 |
| Beck/Arnley | 052-1450 |
| Breda | CR7005 |
| Centric Parts | 417.42016 |
| Chicago Rawhide | 18864 |
| Datsun/Nissan | 40232-16500, 40232-A0101 |
| General Motors | 30006767, 96059934, 96069122 |
| ITM Engine Components | 15-20501, 15-31101, 211-6536, 211-6538, 212-10503, P6536 |
| Lazorlite | L81-7171 |
| Midas | GS1025, GS1383, GS1420 |
| Payen | NJ009, NJ078, NJ999 |
| SKF | 18864, VKBA1967, VKBA684 |
| Timken | 1188S |
| Toyota | 90310-48023, 90312-48001 |
| VICTOR REINZ GASKETS | 611090900 |
| Vera | 65-00615, 6502825 |
| Victor Reinz | 66540, 611090900 |
