Sealed Power 536NP60 - Sealed Power 536NP 60 Engine Piston Set
- Part Number
- 536NP60
- Manufacturer
- SEALED POWER
- Description
-
Sealed Power 536NP 60 Engine Piston Set
details
$25992
Package Price for 8 Units
@ $32.49 per unit
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
SEALED POWER part description
Product Description
Engine Piston Set
Features & Benefits
- Cast - use with E-356K, E-356KC or E-356X ring set
- Performance & dependability of original equipment pistons
- High quality aluminum
- Utilizes ISO & QS certified manufacturing
- Meets or exceeds OEM specifications
Product Attributes
| Oversized | Yes |
| Top Compression Ring Thickness | 0.0781 IN |
| Second Compression Ring Thickness | 0.0781 IN |
| Oil Ring Thickness | 0.1875 IN |
| Piston Pin Outside Diameter | 0.9275 IN |
| Assembly Lubricant Included | No |
| Bore Diameter | 3.7360 IN |
| Piston Material | Cast Aluminum |
| 9607 | 1.540 IN |
| Head Illustration | 29 |
| Head Type | Recessed Head .062 deep x 3.130 dia. |
| Minimum Clearance | 0.001 @ 1.800 from top of head |
| Oversized Amount | 0.060 IN |
| Part Description | Engine Piston |
| Pin Offset (Inch) | 0.06 |
| Pin Offset (MM) | 1.524 |
| Bore Diameter | 94.9 MM |
| Grade Type | Premium |
| Piston Pin Outside Diameter | 23.559 MM |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8409910010 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Harmonized Tariff Code (HTS) | 8409915085 |
| UPC | 00724956362943 |
Part Interchanges
- 536NP 60
- Badger P419-060
- Clevite 9-1493.060
- Clevite TC2558.060
- 1493.060
- Ertel 1224P60
- Z8344 060
- Dana Commercial Vehicle Service Parts 224-2558.060
- Dana Commercial Vehicle Service Parts TC2558.060
- Badger P419060
- Silvolite 1493060
- Clevite 91493060
- Clevite TC2558060
- Sealed Power 9128P60
- Zollner Z8344060
- Dana Commercial Vehicle Service Parts 2242558060
- Dana Commercial Vehicle Service Parts TC2558060
Fits Vehicles
- Oldsmobile Custom Cruiser (1991-1992)
- Pontiac Grand Prix (1987)
- Pontiac Firebird (1987-1992)
- Oldsmobile Cutlass Supreme (1987)
- GMC V1500 (1987)
- GMC R2500 (1987)
- GMC R1500 Suburban (1987)
- GMC R1500 (1987)
- GMC K2500 (1988-1995)
- GMC K1500 (1988-1995)
- GMC Jimmy (1987)
- GMC G2500 (1987-1995)
- GMC G1500 (1987-1995)
- GMC Caballero (1987)
- GMC C2500 (1988-1995)
- GMC C1500 (1988-1995)
- Chevrolet V10 (1987)
- Chevrolet Commercial Chassis (1991-1992)
- Oldsmobile Cutlass (1987)
- Chevrolet R20 (1987)
- Chevrolet R10 Suburban (1987)
- Chevrolet R10 (1987)
- Chevrolet Monte Carlo (1987-1988)
- Chevrolet K2500 (1988-1995)
- Chevrolet K1500 (1988-1995)
- Chevrolet G20 (1987-1995)
- Chevrolet G10 (1987-1995)
- Chevrolet El Camino (1987)
- Chevrolet Caprice (1987-1992)
- Chevrolet Camaro (1987-1992)
- Chevrolet C2500 (1988-1995)
- Chevrolet C1500 (1988-1995)
- Chevrolet Blazer (1987)
- Cadillac Brougham (1991-1992)
- Buick Commercial Chassis (1991)
- Buick Roadmaster (1991)
- Buick Regal (1987)
