(888) 312-8812 Login SignupCENTRIC 123.65013 C-Tek Standard Brake Drum
$113.09
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 123.65013 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.65013 Specifications
Product Attributes
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 9.205 |
| Weight [cntrc] Lbs | 20.250 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 116.840 |
| Hub Hole / Register [cntrc] In | 4.600 |
| Height [cntrc] Mm | 84.074 |
| Height [cntrc] In | 3.310 |
| Friction Surface Width [cntrc] Mm | 63.754 |
| Friction Surface Width [cntrc] In | 2.510 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 310.100 MM |
| Maximum Brake Diameter (Discard) | 12.210 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 347.980 MM |
| Outside Diameter | 13.700 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.260 MM |
| Mounting Hole Diameter | 0.640 IN |
| Nominal Drum Diameter | 308.000 MM |
| Nominal Drum Diameter | 12.125 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890977865 |
CENTRIC 123.65013 Cross References
CENTRIC 123.65013 Fits Vehicles
- GMC 1500 Series (1960-1962)
- Chevrolet Suburban (1960-1963)
- Chevrolet K20 Pickup (1961-1963)
- Ford F-250 (1959-1975)
