(888) 312-8812 Login SignupCENTRIC 120.47010 Centric Premium Brake Rotor
Tap to view 4 more
$4399
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Feb 25
CENTRIC 120.47010 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.47010 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Lbs | 12.000 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 5.450 |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22.000 MM |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24.000 MM |
| Hat Finish | Painted |
| Overall Height | 56.800 MM |
| Overall Height | 2.236 IN |
| Outside Diameter | 260.000 MM |
| Outside Diameter | 10.236 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.283 IN |
| Center Hole Diameter | 58.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.504 IN |
| Stud/Lug Hole Diameter | 12.800 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890031642 |
CENTRIC 120.47010 Cross References
| Brand | Part Number |
|---|---|
| N/A | 0832385, 0832533, BD125045, BD125045E, 6477090, 64 77 090, 26310AA031, 31042, 106406, 31042G, 31059G, 26300AE040, 26300AE090, 26300AE091, 26310AA021, 26310AA030, 26310AA032, 26310AA091, 26310AC060, 26310AC06A, 141698, 4886061, 86061, 375, JBR358, D17509, 1.4714.2.4, 1471424, 120.47010, SU121V, YH141698, X50743, 25369, BR1693, 96061, 96061P, DDF485, DDF679, 8918010, 142949, 90013007 |
| NEOTEK | 106406GF |
| Neotek Premium Drums and Rotors | 106406GF |
| RAYBESTOS | 96061FZN, 96061R |
| Raybestos Brakes | 96061FZN, 96061R |
| WAGNER | BD125045E, BD125045 |
CENTRIC 120.47010 Fits Vehicles
- Subaru Legacy (1990-2000)
- Subaru Impreza (1993-2001)
CENTRIC 120.47010 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 120.47010 Questions & Answers
No questions yet
Be the first to ask a question about this product!
