CENTRIC 120.4508 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Application Summary
Mazda CX-9 2015-2007
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.4508 Specifications
Product Attributes
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 1.102 IN |
| Hat Finish | Coated |
| Overall Height | 1.890 IN |
| Outside Diameter | 319.500 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 72.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.800 MM |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 3 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 10.300 |
| Weight [cntrc] Lbs | 22.650 |
| Nominal Thickness | 28.000 MM |
| Disc Mounting | Floating |
| Misc Holes | 3 |
| Vane Style | Straight |
| Weight | 22.650 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890413097 |
CENTRIC 120.4508 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980580, 980580FZN, 980580R |
| Neotek Premium Drums and Rotors | 106641GF |
CENTRIC 120.4508 Fits Vehicles
- Mazda CX-9 (2007-2015)
