CENTRIC 121.74003 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.74003 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Notes [cntrc] | Hat Shaped |
| Weight [cntrc] Kgs | 13.800 |
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 30.350 |
| Product Grade [cntrc] | Standard |
| Nominal Thickness | 1.571 IN |
| Nominal Thickness | 39.900 MM |
| Overall Height | 2.807 IN |
| Overall Height | 71.300 MM |
| Outside Diameter | 310.000 MM |
| Outside Diameter | 12.205 IN |
| Mounting Bolt Hole Quantity | 12 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 5.472 IN |
| Center Hole Diameter | 139.000 MM |
| Mounting Bolt Hole Circle Diameter | 6.339 IN |
| Mounting Bolt Hole Circle Diameter | 161.000 MM |
| Mounting Bolt Hole Diameter | 10.000 MM |
| Mounting Bolt Hole Diameter | 0.394 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890945338 |
CENTRIC 121.74003 Cross References
CENTRIC 121.74003 Fits Vehicles
- Freightliner FL360 (2010-2012)
- Mitsubishi Fuso Canter FE180 (2012-2014)
- Mitsubishi Fuso Canter FE160 (2012-2014)
- Mitsubishi Fuso FE180 (2005-2011)
