Centric 123.47010 - C-Tek Standard Brake Drum
$4599
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 5.000 |
| Weight [cntrc] Lbs | 11.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 58.000 |
| Hub Hole / Register [cntrc] In | 2.283 |
| Height [cntrc] Mm | 63.200 |
| Height [cntrc] In | 2.488 |
| Friction Surface Width [cntrc] Mm | 43.000 |
| Friction Surface Width [cntrc] In | 1.693 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 230.600 MM |
| Maximum Brake Diameter (Discard) | 9.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 269.500 MM |
| Outside Diameter | 10.610 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.900 MM |
| Mounting Hole Diameter | 0.508 IN |
| Nominal Drum Diameter | 228.500 MM |
| Nominal Drum Diameter | 8.996 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890239857 |
Part Interchanges
CENTRIC 123.47010 Cross Reference
We have 2 alternatives for the 123.47010 by CENTRIC:
Fits Vehicles
- Subaru Legacy (1995-2000)
- Subaru Impreza (1993-2001)
- Subaru Forester (1998-2000)
