CENTRIC 121.65040 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.65040 Specifications
Product Attributes
| Inner Seal # [cntrc] | 417.65000 |
| Inner Bearing # [cntrc] | 410.91013 |
| Disc Mounting [cntrc] | Hub & Rotor |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Standard |
| Outer Bearing # [cntrc] | 410.91012 |
| Weight [cntrc] Lbs | 26.500 |
| Weight [cntrc] Kgs | 12.050 |
| Discard Thickness | 24.450 MM |
| Discard Thickness | 0.963 IN |
| Nominal Thickness | 26.000 MM |
| Nominal Thickness | 1.024 IN |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 133.600 MM |
| Overall Height | 5.260 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 297.400 MM |
| Rotor Outside Diameter | 11.709 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 86.400 MM |
| Center Hole Diameter | 3.402 IN |
| Mounting Bolt Hole Circle Diameter | 139.700 MM |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890050605 |
CENTRIC 121.65040 Cross References
| Brand | Part Number |
|---|---|
| MAGMA PRODUCTS | PMR205156 |
| N/A | BD125404, 52125404, 52-125404, E126-70-045, 54024, BR54024, R92260, 54024G, 107156, F4UA1102AA, F4UZ1102A, F5UA1102TA, F5UZ1102UA, 102324, 102324E, PRT1906, 141906, 86455, 1209, AR8540E, D17709, E12670045, X51002, 27120, BR1961, 1066455, 66455, 66455R, 66455RGS, ZAR8540, 19777, 78942040, 78-42040, 7842040, 65640, 60054130 |
| RAYBESTOS | 66455, 66455FZN, 66455R |
| WAGNER | BD125404, BD125404E |
CENTRIC 121.65040 Fits Vehicles
- Ford E-150 Econoline Club Wagon (1994-2002)
- Ford E-150 Club Wagon (2003)
- Ford E-150 (2003)
- Ford E-150 Econoline (1994-2002)
