CENTRIC 228.37066 Part Description
Manufacturer
Product Description
C-Tek Standard Drilled Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. G11 metallurgy. Drilled for increased bite; improved looks and better performance
CENTRIC 228.37066 Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 181.000 |
| Weight [cntrc] Kgs | 6.480 |
| Product Grade [cntrc] | Standard |
| Disc Mounting [cntrc] | Floating |
| Max Pb Drum Dia [cntrc] In | 7.126 |
| Vane Style [cntrc] | Curved |
| Weight [cntrc] Lbs | 14.250 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 4 |
| Stud/Lug Hole Diameter | 0.606 IN |
| Stud/Lug Hole Diameter | 15.400 MM |
| Stud/Lug Hole Quantity | 5 |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130.000 MM |
| Center Hole Diameter | 3.858 IN |
| Center Hole Diameter | 98.000 MM |
| Bearings Included | No |
| Nominal Drum Diameter | 7.087 IN |
| Nominal Drum Diameter | 180.000 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | X Drilled |
| ABS Tone Ring Included | No |
| Outside Diameter | 11.768 IN |
| Outside Diameter | 298.900 MM |
| Overall Height | 2.681 IN |
| Overall Height | 68.100 MM |
| Nominal Thickness | 0.941 IN |
| Nominal Thickness | 23.900 MM |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22.000 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890459545 |
CENTRIC 228.37066 Cross References
CENTRIC 228.37066 Fits Vehicles
- Porsche Cayman (2009-2012)
- Porsche Boxster (2009-2012)
