CENTRIC 120.6306 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Application Summary
Chrysler 300 2021-2005, Dodge Challenger 2021-2009, Charger 2021-2006, Magnum 2008-2005
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.6306 Specifications
Product Attributes
| Discard Thickness | 8.500 MM |
| Nominal Thickness | 10.000 MM |
| Hat Finish | Coated |
| Overall Height | 2.646 IN |
| Outside Diameter | 320.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 183.900 MM |
| Bearings Included | No |
| Center Hole Diameter | 72.500 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.657 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Hat Id [cntrc] In | 6.075 |
| Hat Id [cntrc] Mm | 154.300 |
| Max Pb Drum Dia [cntrc] In | 7.303 |
| Max Pb Drum Dia [cntrc] Mm | 185.500 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 6.360 |
| Weight [cntrc] Lbs | 14.000 |
| Overall Height | 67.200 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Disc Mounting | Floating / DIH |
| Hat Inside Diameter | 6.075 |
| Maximum Drum Diameter | 7.303 |
| Misc Holes | 0 |
| Weight | 6.360 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890210467 |
CENTRIC 120.6306 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 780254, 780254FZN, 780254R |
| Neotek Premium Drums and Rotors | 107081GF |
CENTRIC 120.6306 Fits Vehicles
- Dodge Magnum (2005-2008)
- Dodge Charger (2006-2022)
- Dodge Challenger (2009-2022)
- Chrysler 300 (2005-2022)
CENTRIC 120.6306 Cross References
We have 4 alternatives for the 120.6306 by CENTRIC:
