Centric 122.48000 - Centric Premium Brake Drum
$8449
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
Product Attributes
| Weight [cntrc] Kgs | 4.091 |
| Weight [cntrc] Lbs | 9.000 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 55.400 |
| Hub Hole / Register [cntrc] In | 2.181 |
| Height [cntrc] Mm | 65.500 |
| Height [cntrc] In | 2.579 |
| Friction Surface Width [cntrc] Mm | 42.000 |
| Friction Surface Width [cntrc] In | 1.654 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 181.000 MM |
| Maximum Brake Diameter (Discard) | 7.126 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 218.000 MM |
| Outside Diameter | 8.583 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 10.000 MM |
| Mounting Hole Diameter | 0.394 IN |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | IT |
| UPC | 805890032625 |
Part Interchanges
CENTRIC 122.48000 Cross Reference
We have 2 alternatives for the 122.48000 by CENTRIC:
Fits Vehicles
- Suzuki Forsa (1985-1988)
- Chevrolet Sprint (1985-1988)
