GROTE part description

Technical specifications

Amperage: 7.5Amps @125°C (257°F)
Gauge: 24-20 GA
Series: DTM Series
Operating Temperature: -55°C (-67°F) to 125°C (257°F)
Crimp Style: Solid Barrel
OEM #: 0462-201-20141
Type: Female e

Grote's Deutsch DTM series environmentally sealed connectors are designed specifically for cable to cable applications. With an operating temperature of -55°C (-67°F) to 125°C (257°F), these connectors are ideal for use under the hood, transmission, lighting connections, and other engine compartments.

Features & Benefits
  • Ideal for use under the hood, transmission, lighting connections and other engine compartments
  • Nickel-plated contacts
  • Operating temperature -55°C (-67°F) to 125°C (257°F)
  • Current rating 7.5 amps @ 125°C (257°F) continuous
  • Designed for lower amperage connectors
Gauge 24 - 20

Product Description

Deutsch, Solid Barrel, 24; 20 Ga, Female, Pk 10

Product Attributes

Amperage 7.5Amps @125 degree C (257 degree F)
Crimp Style Solid Barrel
Gauge 24-20 GA
Operating temperature -55 degree C (-67 degree F) to 125 degree C (257 degree F)
Prop 65 Label Required N
Series DTM Series
Type Female

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8536900000
OEM's Part Number 0462-201-20141
UPC 00621935093075
VMRS Code 053007002

Established in 1901, Grote® is a world-class manufacturer and supplier of light components and smart visibility systems for heavy duty vehicles. From LED beacons to trailer connectors, Grote products provide effective solutions and added value to its customers in the agricultural, construction, freight, and mining industries. The company has been a major supplier to commercial vehicle manufacturers, utilizing the latest quality planning techniques and manufacturing systems as well as rigorous environmental testing to maintain their competitive edge. Grote also works closely with OEM distributors and fleet managers in developing new ways to maximize the efficiency of their products according to the demands of the market.
