(888) 312-8812 Login SignupBENDIX K041960 Spring Brake (Disc)
MSRP: $680.24
$36449
Save $315.75
Limited availability at this price!
In Stock
Get as soon as Wednesday, Oct 7
BENDIX K041960 Part Description
Manufacturer
Product Description
Spring Brake (Disc)
Features & Benefits
- Joins service-brake and parking-brake functions in one spring chamber
- Separates the two actuator sections with a double-diaphragm design
- Type 20/24 sizing defines the service and spring sections of the chamber
- Standard-stroke arrangement distinguishes this disc-brake actuator configuration during service
Bendix Air Brake Spring Brake
The Bendix Air Brake Spring Brake combines Type 20 service-brake actuation with a Type 24 spring section for compatible disc-brake applications. The Bendix K041960's combination-chamber design handles normal service braking and mechanically applied parking or emergency brake force within one actuator. The spring brake uses a standard-stroke arrangement and a double-diaphragm design for the two brake sections. Chamber size and mounting application should be confirmed because Type 20/24 spring brakes can differ in stroke, clevis, and mounting details.
BENDIX K041960 Specifications
Product Attributes
| Cautionary Note(s) | All vent holes must be open |
| Chamber Style | Double Diaphragm |
| Chamber Type / Size | T20/24 |
| Clamp Angle | 90Adeg |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 176 AdegF (80 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting Stud Length | 1.73 IN (43.9 MM) |
| Parking Chamber Sealed | No |
| Parking Port (12) | 3/8-18 NPTF |
| Port Angle | 270Adeg |
| Push Rod Length [MM] | 15 mm |
| Push Rod Thread / Style | Spherical End |
| Service Chamber Joint Type | Single Clamp Band |
| Service Chamber Vent Holes | All Open |
| Service Port (11) | 3/8-18 NPTF |
| Stroke | 2.50 IN (63.5 MM) |
| Stud Spacing | 4.75 IN (120.7 MM) |
| Stud Thread Size | M16 x 1.5-6g |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078217252 |
| VMRS Code | 013013048 |
BENDIX K041960 Cross References
| Brand | Part Number |
|---|---|
| BWK041960, OTR-2024AD | |
| BWP | M-5301 |
| BWP-NSI | M-5301 |
| MERITOR | 2016HTND23710 |
| N/A | 800921 |
| TORQSTOP | TST2024 |
| WORLD AMERICAN | WAK041960 |
