WABCO 9617232000 - Parking Brake Valve - Hand Brake Valve
$1,09499
MSRP: $2,057.95
Save: $962.96
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Weight | 1.36 |
| Max. operating pressure | 145.04 psi |
| Calculated Volume (dm³) | 1.4446 |
| Size | 176 x 108 x 76 |
| Temperature Range | -40°C to +80°C |
| Distance Between Holes | 80 mm |
| Color | Black/Black |
| Exhaust | Hose Nozzle Ø 6 mm |
| Port thread 22 | M16 x 1.5 JED - 464 |
| Port thread 21 | M16 x 1.5 JED - 464 |
| Port thread 1 | M16 x 1.5 JED - 464 |
| Mounting | M6 |
| Port threads | M16 x 1.5 VOSS |
| Actuation Angle | 85° |
WABCO 9617232000 Cross Reference
We have 1 alternatives for the 9617232000 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
