(888) 312-8812 Login SignupMERITOR R4709 Drum Brake Shoe - 16.5 in. Brake Diameter
Tap to view 2 more
SHIPS TODAY
MSRP: $94.92
$5599
Save $38.93
Limited availability at this price!
In Stock
Get it by Monday, Jul 20
MERITOR R4709 Part Description
Manufacturer
Product Description
BRAKE SHOE
Features & Benefits
- Uses a stamped steel table designed to limit deflection under brake load
- Incorporates a welded web to keep the shoe aligned during expansion
- Relies on riveted lining attachment to maintain secure block retention
- Sized for 16.5-inch drum brake applications on heavy-duty trailers
- Maintains even lining-to-drum contact across the braking surface
Meritor Drum Brake Shoe
Drum brake performance depends on the stability of the shoe under load, and the Meritor Drum Brake Shoe provides the structural base required for consistent braking in heavy-duty trailer applications. This 16.5-inch brake shoe uses a stamped and coined steel table designed to limit deflection as braking force is applied. The shoe web is welded to the table to keep the assembly aligned as it expands against the drum during operation. Friction lining is attached using rivets selected to hold securely as temperatures rise and fall through repeated brake cycles. Maintaining proper shoe shape allows the lining to contact the drum evenly rather than loading one edge. The Meritor R4709 shoe is supplied as a foundation component ready to accept compatible linings for service.
MERITOR R4709 Specifications
Product Attributes
| Application Information | Eaton ES I. |
| Brake Diameter | 16.50 in. |
| Brake Shoe Width | 7.00 in. |
| Brake Type | ES I |
| Brand | Meritor |
| FMSI | 4709 |
| Friction Type | Unlined |
| Lining Number | Unlined |
| Lining Weight Rating | NA |
| Oe Mfg. | Eaton |
| Pallet Quantity | 100 |
| Rivet Hole Count | 28 |
| Rivet Number | RV3109S |
| Rivet Size | 0.25 in. |
| Weight | 12.40 |
MERITOR R4709 Cross References
| Brand | Part Number |
|---|---|
| BWP | M3190 |
| DANA SPICER | 4709E, 4709ETN |
| EATON | 806229 |
| Spicer | 4709E, 4709ETN |
