TECTRAN 2000 - Air Brake Reservoir - 32 in. Length, 8 in. O.D, 1425 Vol Cu. In., Type 1
$21399
In stock
limited availability at this price!
. Learn more
TECTRAN part description
California Proposition 65 Warning
California Proposition 65 Warning
Air Tank - 1425 Cu. In., 8" O.D., 32" Length, Standard Bracket
| Product Specifications: | |
| Volume: | 1425 Cu. In. |
| Length: | 32" |
| Bracket Type: | Standard |
| Port A Size: | 3/4" |
| Port B Size: | 3/8" |
| Port C Size: | 1/4" |
| Port D Size: | No |
| O.D.: | 8" |
Features & Benefits
- Every tank is pressure tested for leak resistance, structural integrity, and safety
- A unique, automated painting process applies a corrosion-resistant paint to both the inside and outside surfaces, providing long-lasting rust protection
- Continuous weld seams ensure a sound and secure tank body
- Ports are resistance-welded for strength and leak protection
- Threads are gauged to "L Standards"
- Each tank is date-coded for traceability
- Maximum working pressure: 150 psi
- Air tanks meet SAE J10 and FMVSS DOT 121 for use in Heavy Duty Air Brake systems
- Length refers to the distance between mounting hole centers on each end bracket
- Holes in the mounting brackets are drilled at 7/16" diameter
Product Description
Air Tank - 1425 Cu. In., 8" O.D., 32" Length, Standard Bracket
Additional Information
| Country of Origin (Primary) | US |
| UPC | 00827030110079 |
TECTRAN 2000 Cross Reference
We have 11 alternatives for the 2000 by TECTRAN:
Since 1972, Tectran® has been a leading designer and manufacturer of high-performance tractor and trailer connection systems based in Buffalo, New York. The company is highly recognized for its range of AirPower hook-up lines, which come with revolutionary features such as kink-resistant tapered grips and rust-resistant brass construction. The company also offers a one-stop shop for line clamps, fittings, plugs and sockets, air tanks, junction boxes, trailer brackets, and other related parts and accessories. Tectran products are designed for the latest and older models of trucks, trailers, and buses, and they can withstand the most demanding applications. Each product is also built, assembled, and tested in-house to ensure safety and optimum performance.
