DELPHI CZ20007 Part Description
Manufacturer
Product Description
Distributor
Features & Benefits
- Delphi parts are built to meet or exceed OE requirements
- OE quality replacement parts for the right fit, form and function
- Designed to operate as part of an integral engine management system to distribute into spark plugs and ensure fast starts and consistent performance
- We back our ignition parts with proven materials, such as high quality stainless steel, iron, and plastics
DELPHI CZ20007 Specifications
Product Attributes
| Interface Description | 3 Pin Sealed Connector, 1 HV tower to Coil, 6 HV Tower to Plugs via Wire Sets |
| Notes | HV Towers Located Horizontally for V6 Apps. |
| Package Contents | Distributor |
| Length | 12.4 IN |
| Length | 315.0 MM |
| Color | Black and Silver |
| Coil Wire Included | No |
| Operation Type | HVS |
| Terminal Type | Blade |
| Grade Type | Standard Replacement |
| Cap Color | Black |
| Terminal Quantity | 3 |
| Terminal Gender | Male |
| Ignition Box Required | No |
| Advance Type | Mechanical |
| Marine Approved | No |
| Ignition Coil Included | No |
| Distributor Cap Included | Yes |
| Ignition Rotor Included | Yes |
| Ignition Module Included | No |
| Adjustable Collar | No |
| Mechanical Tach Drive Provision | No |
| Cap Terminal Gender | Male |
| Clamp Included | No |
| Clamp Hardware Included | No |
| 10594 | 45.7 MM |
| Distributor Gear Included | Yes |
| Gear Material | Composite |
| Housing Finish | Uncoated |
| Shaft Length | 7.79 IN |
| Shaft Material | Alloy |
| Connector Type | Sealed |
| Housing Material | Aluminum |
| Shaft Color | Silver |
| Shaft Diameter | 1.25 IN |
| Housing Color | Black |
| Trigger Type | Hall Effect |
| Rotor Rotation | Counterclockwise (Left) |
| Gear Tooth Quantity | 13 |
| Computer Controlled Compatible | No |
| 10594 | 1.8 IN |
| Shaft Length | 197.8 MM |
| Shaft Diameter | 31.7 MM |
| 10594 | 4.6 CM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511300040 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604125373 |
| VMRS Code | 033002001 |
| UNSPSC | 26101700 |
DELPHI CZ20007 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 12570426 |
| CARDONE Reman | 301639 |
| Dorman | 690-900 |
| Echlin | DA101 |
| General Motors | 10458103, 1104078, 12570426, 12598210, 93441559 |
| Isuzu | 8-12598-210-0, 8-93441-559-0 |
| N/A | 690900, 8125982100, 8934415590 |
| NAPA Reman Computers | 481639 |
| Original Engine Management | DA6 |
| STANDARD IGNITION | DSA101 |
| Standard Motor Products | Z95002 |
| WPS World Power Systems | DST1639 |
DELPHI CZ20007 Fits Vehicles
- Chevrolet Astro (1996-2005)
- Chevrolet Blazer (1995-2005)
- Chevrolet C1500 (1996-1998)
- Chevrolet Express 1500 (1996-2005)
- Chevrolet Express 2500 (1997-2005)
- Chevrolet K1500 (1996-1998)
- Chevrolet P30 (1996-1999)
- Chevrolet S10 (1995-2004)
- Chevrolet Silverado 1500 (1999-2005)
- GMC C1500 (1996-1998)
- GMC Jimmy (1995-2001)
- GMC K1500 (1996-1998)
- GMC P3500 (1996-1999)
- GMC Safari (1996-2005)
- GMC Savana 1500 (1996-2005)
- GMC Savana 2500 (1998-2005)
- GMC Sierra 1500 (1999-2005)
- GMC Sonoma (1996-2004)
- Oldsmobile Bravada (1996-2001)
