CENTRIC 123.50005 C-Tek Standard Brake Drum

★★★★★ (0)
123.50005 by CENTRIC - C-Tek Standard Brake Drum
CENTRIC
Tap to view 4 more

$54.49

Limited availability at this price!

1 Day Lead Time

Get it by Thursday, Jun 25
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
This item will ship about 1 day after the date of purchase.

CENTRIC 123.50005 Part Description

Manufacturer

CENTRIC

Product Description

C-Tek Standard Brake Drum

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
  • For best operation and ultimate strength
  • OE-Matched Fit, Form, and Function
  • 100% Mill Balanced
  • For vibration free performance
  • Meets SAE Standard for Tensile Strength
  • For maximum service life and structural integrity

CENTRIC 123.50005 Specifications

Product Attributes

Weight [cntrc] Kgs 5.909
Weight [cntrc] Lbs 13.000
Mounting Type [cntrc] Hub & Drum
Bolt Circle Diameter [cntrc] Mm 100.000
Bolt Circle Diameter [cntrc] In 3.937
Stud Thread Pitch [cntrc] Mm 1.50
Hub Hole / Register [cntrc] Mm 54.500
Hub Hole / Register [cntrc] In 2.146
Height [cntrc] Mm 68.000
Height [cntrc] In 2.677
Friction Surface Width [cntrc] Mm 34.200
Friction Surface Width [cntrc] In 1.346
Product Grade [cntrc] Standard
Stud Thread Size 12 MM
Maximum Brake Diameter (Discard) 201.500 MM
Maximum Brake Diameter (Discard) 7.933 IN
Bolt Hole Quantity 4
Outside Diameter 230.000 MM
Outside Diameter 9.055 IN
Outer Cooling Fins No
Nominal Drum Diameter 200.000 MM
Nominal Drum Diameter 7.874 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 00805890914877

CENTRIC 123.50005 Cross References

BrandPart Number
N/ABD126169, 0832949, 35111, BD35111, FD100D, 35111G, 52725FD200, 123.50005, 9772, PDR0824, 9772DGS, 36521005
PRONTOBD35111
RAYBESTOS9772, 9772R

CENTRIC 123.50005 Fits Vehicles

  • Kia Rio (2003-2005)
