(888) 312-8812 Login SignupMOOG CC878 MOOG CC878 Coil Spring Set
Tap to view 3 more
$665.77
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MOOG CC878 Part Description
Manufacturer
Product Description
Coil Spring Set
Application Summary
1997-1998 Ford E-250 Econoline Base (Front) (Qualifier: with 8450 (lb) & 8550 (lb) GVW, Variable Rate); 1992-1996 Ford E-350 Econoline Base XL (Front) (Liter: 5.8, 4.9 / Qualifier: with TRAILER TOW Package, Variable Rate, Heavy Duty, without Towing Package, Except 9500 (lb) GVW, with 9,500 (lb) Gross Vehicle Weight (GVW)); 1992-1996 Ford E-350 Econoline Club Wagon (Front) (Liter: 5.8, 4.9 / Qualifier: with TRAILER TOW Package, Variable Rate, Heavy Duty, without Towing Package)
Features & Benefits
- 100% Load tested
- Easy to install
- Provides like-new steering
- Designed to lower stresses for longer service life
- Worn or sagging coil springs can cause premature tire wear due to vehicle misalignment
Moog Front Coil Springs OE comparable -MOOG COIL SPRINGS, SOLD AS PAIR -- Variable Rate Springs, Made From Heat-Treated Alloy Steel For A Full Coil Rebound And Sagging Resistance, Change Resistance When Compressing, Become Progressively Stiffer As Its Load Increases, Use A Premium Urethane Tube That Lasts Much Longer, Vinyl-Coated For Corrosion Resistance And Extended Service LifeFront
MOOG CC878 Specifications
Product Attributes
| Wire Diameter | 0.78 IN |
| Wire Diameter | 19.80 MM |
| Spring Color | Black |
| Front Spring Outside Diameter | 5.620 IN |
| Front Spring Relaxed Length | 15.75 IN |
| Front Spring Relaxed Length | 400.10 MM |
| Front Spring Compressed Length | 13.00 IN |
| Front Spring Compressed Length | 330.20 MM |
| Rear Spring Relaxed Length | 15.75 IN |
| Rear Spring Relaxed Length | 400.10 MM |
| Rear Spring Compressed Length | 13.00 IN |
| Rear Spring Compressed Length | 330.20 MM |
| Rear Spring Outside Diameter | 5.620 IN |
| Bar Diameter (in.) | 0.78 |
| Bar Diameter (mm) | 19.8 |
| End Type 1 | Pigtail |
| End Type 2 | Pigtail |
| Free Height (in.) | 15.75 |
| Free Height (mm) | 400.1 |
| ID (in.) | 3.98 |
| ID (MM) | 101.2 |
| Installation Height (in.) | 13 |
| Installation Height (mm) | 330.2 |
| Load (lbs) | 1687 |
| Spring Rate (lbs Per in.) | 589 |
| Spring Type | Variable Rate |
| Bar Diameter - Inches | 0.78 |
| Bar Diameter - MM | 19.80 |
| End 1 Type | Pigtail |
| End 2 Type | Pigtail |
| Free Height - Inches | 15.75 |
| Free Height - MM | 400.10 |
| ID - Inches | 3.98 |
| ID - MM | 101.20 |
| Installation Height - Inches | 13.00 |
| Installation Height - MM | 330.20 |
| Load - lbs | 1687.00 |
| Part Description | Coil Spring Set |
| Spring Rate - lbs per inch | 589.00 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Remanufactured Part | N |
| Refurbished Part | N |
| UPC | 00080066405759 |
| VMRS Code | 016002002 |
| UNSPSC | 31161903 |
MOOG CC878 Cross References
| Brand | Part Number |
|---|---|
| 080066405759 | |
| ACDelco | 45H1089 |
| Centric Parts | 630.65056 |
| Duralast | FCS878V |
| Duralast Gold | DG5871089 |
| Ford | F2UZ-5310M |
| Mcquay-Norris | FCS878V |
| Mevotech | SMS878V |
| Mevotech Supreme | SMS878V |
| NAPA | 277-5322 |
| NAPA Chassis Parts | 277-5322 |
| Perfect Circle | 277-5322 |
| Pontotoc | U878FV |
| Raybestos Brakes | 587-1089 |
| Sealed Power | 832-878 |
| TRW | CC878 |
| TRW Steering and Suspension Parts | CC878, JCS1453T |
MOOG CC878 Fits Vehicles
- Ford E-350 Econoline Club Wagon (1992-1996)
- Ford E-350 Econoline (1992-1996)
- Ford E-250 Econoline (1997-1998)
MOOG CC878 Customer Reviews
No reviews yet
Be the first to review this product!
MOOG CC878 Manufacturer Information
For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
