MONROE part description

Product Description

Magnum Steering Damper

Features & Benefits

  • REDUCES VIBRATION -- Ideal for trucks, vans, SUVs, and CUVs, it helps reduce vibrations that travel through the steering system before they get to the driver to improve control and cut down on driver fatigue in all driving conditions
  • CONSISTENT PERFORMANCE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • STRONG AND DURABLE -- Sintered iron piston and .50-in. nitrocarburized piston rod for enhanced durability and long service life
  • EXCEPTIONAL HANDLING -- Full displaced valving delivers better valving range on both compression and extension cycles for consistent performance
  • LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas without excessive wear or friction
  • MOUNTS HORIZONATALLY -- Micro-cellular gas design allows the unit to be mounted horizontally without impacting performance for improved steering control

Product Attributes

Compressed Length 13.0000 IN
Extended Length 21.3750 in
Shock Absorber Body End Measuring Point Center of Loop
Travel Length 8.3750 in
Body Diameter 1.8600 IN
Lower Mount Type Loop Bushing And Sleeve Mount - 12mm Sleeve ID X 38.1mm Sleeve OAL
Lower Mount Code LS26
Upper Mount Type Loop Bushing And Sleeve Mount - 12mm Sleeve ID X 38.1mm Sleeve OAL
Upper Mount Code LS26
Dust Shield Included No
Dust Shield Material N/A
Gas Charged No
Parts Pack(s) None
Shock Absorber Rod End Measuring Point Center of Loop
Adjustable Damping No
Internal Construction Type Twin Tube
Color Black
Finish Painted
9804 Yes
Shaft Diameter 16 MM
Part Description Steering Damper

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708949900
Harmonized Tariff Code (Schedule B) 8708947550
Harmonized Tariff Code (HTS) 8708947550
UPC 00048598029362
VMRS Code 015004022
UNSPSC 25174202

Part Interchanges

MONROE SC2955 Cross Reference

We have 4 alternatives for the SC2955 by MONROE:

Fits Vehicles

  • Ford E-550 Super Duty (2003)
  • Ford E-550 Econoline Super Duty (2002)
  • Ford Excursion (2005)
  • Ford E-350 Super Duty (1999-2019, 2021-2023)
  • Ford E-450 Econoline Super Duty (2000-2002)
  • Ford F-350 Super Duty (1999-2010)
  • Ford F-350 (1992-1997)
  • Ford F-250 Super Duty (1999-2010)
  • Ford F-250 (1992-1996)
  • Ford E-350 Econoline Club Wagon (1992-2002)
  • Ford E-350 Club Wagon (2002-2005)
  • Ford E-350 Econoline (1992-2000)
  • Ford E-250 (2003-2004)
  • Ford E-250 Econoline (1996-2002)
  • Ford E-450 Super Duty (2003-2019, 2021-2022)
  • Ford Econoline Super Duty (1996-1999)
