(888) 312-8812 Login SignupMONROE MA810 Max-Air Aire ajustable Amortiguador de Suspensión Neumática Paquete de 2
Tap to view 3 more
$19299
Limited availability at this price!
In Stock
Get it by Friday, Jul 17
MONROE MA810 Part Description
Manufacturer
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA810 Specifications
Product Attributes
| Compressed Length | 12.375 IN |
| Compressed Length | 314.3 MM |
| Extended Length | 520.7 MM |
| Extended Length | 20.5 in |
| Travel Length | 8.125 in |
| Travel Length | 206.4 MM |
| Lower Mount Type | Loop Bushing and Cantilever Pin Mount - 1/2" Stud Diameter X 1 5/16" Stud Length (Center of Loop to Frame) |
| Lower Mount Code | L1/CP3 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Parts Pack(s) | P00576,P01136 |
| Part Description | Air Shock Absorber |
| Boot Included | Yes |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Grade Type | Premium |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598031235 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA810 Cross References
| Brand | Part Number |
|---|---|
| MA810MM, JK4Z1504567EA | |
| Chevrolet | 4993581, 4993582, 88945998 |
| Ford | E3DZ18125H, E4AZ18125A, E4DZ18124A, E5DZ18124A, E5DZ18124B, E5DZ18125A, E6PZ18124B, E7PZ18125C, E7ZZ18124A, E8ZZ18125A, E9AZ18124A, E9AZ18124B, E9AZ18125A, E9AZ18125B, E9AZ18125G, E9ZZ18125A, FOAZ18125A, FOAZ18125B, FOZZ18124A |
| GABRIEL | 49199 |
| Mercury | E3DZ18125H, E4DZ18124A, E5DZ18124A, E5DZ18124B, E5DZ18125A, E6PZ18124B, E7PZ18125C, E8ZZ18125A |
| NAPA Shocks | MA810 |
| Pontiac | 4993581, 4993582 |
MONROE MA810 Fits Vehicles
- Nissan 2000 (1968-1970)
- Nissan 510 (1969-1973)
- Pontiac Acadian (1976-1987)
- Nissan 710 (1974-1977)
- Mercury Zephyr (1978-1983)
- Mercury Marquis (1983-1986)
- Mercury Cougar (1981-1982)
- Mercury Grand Marquis (1979-1982)
- Mercury Capri (1979-1986)
- Ford Mustang (1979-1993)
- Ford LTD (1983-1986)
- Ford Granada (1981-1982)
- Ford Fairmont (1978-1983)
- Pontiac T1000 (1981-1987)
- Chevrolet Chevette (1976-1987)
