(888) 312-8812 Login SignupMONROE MA773 Max-Air Air Adjustable Air Shock Absorber Pack of 2
Tap to view 3 more
MSRP: $169.42
$13699
Save $32.43
Limited availability at this price!
In Stock
Get it by Friday, Feb 20
MONROE MA773 Part Description
Manufacturer
Product Description
Max-Air Air Adjustable Air Shock Absorber Pack of 2
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA773 Specifications
Product Attributes
| Compressed Length | 13.5 IN |
| Extended Length | 21.75 in |
| Travel Length | 8.25 in |
| Lower Mount Code | LS26 |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Upper Mount Code | L1 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Includes Bump Stop | Yes |
| Hydraulic Lockout | No |
| Parts Pack(s) | None |
| Part Description | Air Shock Absorber |
| Internal Rebound Bumper | Yes |
| Compressed Length | 342.9 MM |
| Extended Length | 552.4 MM |
| Travel Length | 209.5 MM |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Boot Included | Yes |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Grade Type | Premium |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598031501 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA773 Cross References
| Brand | Part Number |
|---|---|
| MA773MM, JC3Z2662901CA | |
| Ford | E3TZ18124N, E7TZ18124G, E7TZ18124L, E7TZ18124M, E7TZ18125N, E7TZ18125P, E7XZ18124B, E7XZ18124E, E7XZ18125C, F2TZ18125L, F4TZ18124E, F4TZ18124F, F4TZ18124G, F4TZ18124J, F4TZ18124K, F4TZ18124M, F4TZ18125J, F4TZ18125K |
| GABRIEL | 49197 |
| Jeep | 4638190, 4638192, 4723035, 4723036, 4740231, 4741675, 4741676, 4883368AC, 4897794AA, 52087840, 52087901, 52088164, 52088202, 52088202AC, 52088578, 52089057 |
| NAPA Shocks | MA773 |
MONROE MA773 Fits Vehicles
- Ford F-150 (1980-1984)
- Ford F-100 (1980-1983)
- Ford Bronco (1980-1996)
- Jeep Grand Cherokee (1993-1998)
