MONROE 65411 Part Description
Manufacturer
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65411 Specifications
Product Attributes
| Compressed Length | 16.375 IN |
| Compressed Length | 415.9 MM |
| Extended Length | 26.5 in |
| Extended Length | 673.1 MM |
| Travel Length | 10.125 in |
| Travel Length | 257.2 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Upper Mount Code | LS54 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173119 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65411 Cross References
| Brand | Part Number |
|---|---|
| 65411MM, MAE65411 | |
| Automann | A85036 |
| BULLDOG HD SHOCKS | HD1215-0078 |
| Blue Bird | 14605 |
| CHEVROLET | 3919956 |
| Dayton Parts | 441850365411 |
| FCS | F347307, F347200 |
| FORD | E9HS18045AA |
| GABRIEL | 85036, 89405 |
| GM | 3919956 |
| General Motors | 3919956 |
| Gold Shock Absorber | 8160907, 9180125 |
| HALDEX | SA65411 |
| HENDRICKSON | 573241, 4790220 |
| Hendrickson | 4790219, 479029, 60665025, 60665025L, 6067513 |
| INTERNATIONAL | AMS650411 |
| KENWORTH | 201759 |
| KONI | 881559SP1 |
| KYB | 341624, 345614, 345615, 341613 |
| KYB AMERICA LLC. | 341624 |
| Kenworth | 4790219 |
| MACK | 14QK366P2, 14QK2100P6, 5625151, 14QK393AM, 14QK366P1, 14QK366, 650411MT, 14CK366P1, 650411, 25625151, 14QK366P3 |
| MERITOR | M89405, M85036 |
| MONROE VINTAGE | 650411, 70310, 66661 |
| Mack | 22314111, 479029, 6067513, 23568046 |
| Monroe Shocks & Struts | 650411, 66661, 70310 |
| Motorcraft | CAX916 |
| NAPA Shocks | 65411 |
| NEWAY | 57365411 |
| OEM | 6067513, 202142, 25625151, 479029, 22314111, 14QK366P2, 14QK366, 14QK366P1, 4790219, 14QK393AM, 202740, 14QK2100P6, 14QK366P3, 14605, 0202142, 0202740 |
| PACCAR PARTS | 665783 |
| PETERBILT | 201759, 202142, 202740 |
| POWER10 PARTS | SSA-85036 |
| Peterbilt | 0202142, 0202740, 0201759 |
| SACHS NORTH AMERICA | 410025 |
| Sachs | 410025 |
| VOLVO / WHITE / GMC | SA5036, 3919956 |
| Volvo GM Heavy Truck | 3919956, SA5036 |
MONROE 65411 Fits Vehicles
- Mack Granite (2015-2024)
- Autocar LLC. Xpert (2020)
- Mack TD700 (2010-2017)
- Peterbilt 587 (2011-2015)
- Mack CV (2001-2008)
- Peterbilt 389 (2008-2021)
- Mack U (1981-1989)
- Mack RB (1989-2005)
- Mack GU8 (2008-2018)
- Mack GU7 (2008-2018)
- Peterbilt 388 (2008-2015)
- Peterbilt 386 (2006-2016)
- Peterbilt 377 (1987-2001)
- Peterbilt 362 (1981-2006)
- Peterbilt 384 (2008-2016)
- Peterbilt 385 (1996-2007)
- Peterbilt 376 (1988-1992, 1994-1996, 1999)
- Peterbilt 375 (1987-1996)
- Mack RD (1981-2004, 2007)
- Mack R (1981-1991)
- Mack MR (1981-2007)
- Peterbilt 379 (1986-2007)
- Peterbilt 378 (1988-2007)
- Peterbilt 357 (1986-2008)
- Kenworth W900 (1981-2018)
- Kenworth T800 (1987-2020)
- Kenworth T600A (1986-2008)
- Peterbilt 387 (2000-2011)
- Kenworth T300 (1995-2008)
- Kenworth K300 (1993-2005)
- Ford FT900 (1990-1993)
- Ford F-800 (1990)
- Ford F-700 (1989-1994)
- Ford F-600 (1989-1994)
