MONROE 65411 Magnum Suspension Shock Absorber

$86.99

Limited availability at this price!

In Stock

Get it by Friday, Jan 30
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 65411 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65411 Specifications

Product Attributes

Lower Mount Code LS54
Upper Mount Code LS54
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Compressed Length 16.375 IN
Dust Shield Material Metal
Extended Length 26.5 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Parts Pack(s) None
Travel Length 10.125 in
Upper Mount Type Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Compressed Length 415.9 MM
Extended Length 673.1 MM
Travel Length 257.2 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598173119
VMRS Code 016008003
UNSPSC 25172011

MONROE 65411 Cross References

BrandPart Number
65411MM, MAE65411
AutomannA85036
BULLDOG HD SHOCKSHD1215-0078
Blue Bird14605
CHEVROLET3919956
Dayton Parts441850365411
FCSF347307, F347200
FORDE9HS18045AA
GABRIEL85036, 89405
GM3919956
General Motors3919956
Gold Shock Absorber8160907, 9180125
HALDEXSA65411
HENDRICKSON573241, 4790220
Hendrickson4790219, 479029, 60665025, 60665025L, 6067513
INTERNATIONALAMS650411
KENWORTH201759
KONI881559SP1
KYB341624, 345614, 345615, 341613
KYB AMERICA LLC.341624
Kenworth4790219
MACK14QK366P2, 14QK2100P6, 5625151, 14QK393AM, 14QK366P1, 14QK366, 650411MT, 14CK366P1, 650411, 25625151, 14QK366P3
MERITORM89405, M85036
MONROE VINTAGE650411, 70310, 66661
Mack22314111, 479029, 6067513
Monroe Shocks & Struts650411, 66661, 70310
MotorcraftCAX916
NAPA Shocks65411
NEWAY57365411
NavistarAMS650411
OEM6067513, 202142, 25625151, 479029, 22314111, 14QK366P2, 14QK366, 14QK366P1, 4790219, 14QK393AM, 202740, 14QK2100P6, 14QK366P3, 14605, 0202142, 0202740
PACCAR PARTS665783
PETERBILT201759, 202142, 202740
POWER10 PARTSSSA-85036
Peterbilt0202142, 0202740, 0201759
SACHS NORTH AMERICA410025
Sachs410025
VOLVO / WHITE / GMCSA5036, 3919956
Volvo GM Heavy Truck3919956, SA5036

MONROE 65411 Fits Vehicles

  • Autocar LLC. Xpert (2020)
  • Mack TD700 (2010-2017)
  • Peterbilt 587 (2011-2015)
  • Mack CV (2001-2008)
  • Peterbilt 389 (2008-2018)
  • Mack U (1981-1989)
  • Mack RB (1989-2005)
  • Mack GU8 (2008-2018)
  • Mack GU7 (2008-2018)
  • Peterbilt 388 (2008-2015)
  • Peterbilt 386 (2006-2016)
  • Peterbilt 377 (1987-2001)
  • Peterbilt 362 (1981-2006)
  • Peterbilt 384 (2008-2016)
  • Peterbilt 385 (1996-2007)
  • Peterbilt 376 (1988-1992, 1994-1996, 1999)
  • Peterbilt 375 (1987-1996)
  • Mack RD (1981-2004, 2007)
  • Mack R (1981-1991)
  • Mack MR (1981-2007)
  • Peterbilt 379 (1986-2007)
  • Peterbilt 378 (1988-2007)
  • Peterbilt 357 (1986-2008)
  • Kenworth W900 (1981-2018)
  • Kenworth T800 (1987-2020)
  • Kenworth T600A (1986-2008)
  • Peterbilt 387 (2000-2011)
  • Kenworth T300 (1995-2008)
  • Kenworth K300 (1993-2005)
  • Ford FT900 (1990-1993)
  • Ford F-800 (1990)
  • Ford F-700 (1989-1994)
  • Ford F-600 (1989-1994)
