(888) 312-8812 Login SignupMONROE 58620 Load Adjusting Ensemble amortisseur avec ressort Un paquet de 2
Tap to view 5 more
MSRP: $296.50
$17599
Save $120.51
Limited availability at this price!
In Stock
Get it by Friday, Jul 10
MONROE 58620 Part Description
Manufacturer
Features & Benefits
- REDUCES SAG UNDER LOAD -- Ideal for occasionally hauling or towing varying loads; heavy gauge, calibrated coil spring reduces sag when loaded up to 1,200 lbs. (capacity limited by suspension, tires and transmission; see owner's manual)
- EXCEPTIONAL HANDLING -- Tuned specifically for each application, full-displaced valving automatically adjusts to road extremes to provide ride consistency
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and PTFE-banded piston helps reduce friction between the piston and pressure tube to enhance responsiveness to changing road surfaces
- LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while heavy-duty nitrocarburized rod delivers long life
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
MONROE 58620 Specifications
Product Attributes
| Compressed Length | 285.8 MM |
| Compressed Length | 11.25 IN |
| Extended Length | 17.0 in |
| Extended Length | 431.8 MM |
| Travel Length | 146 MM |
| Travel Length | 5.75 in |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.5/8" Sleeve OAL |
| Lower Mount Code | LS28 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 41.28MM Sleeve OAL |
| Upper Mount Code | LS28 |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Parts Pack(s) | None |
| Part Description | Shock Absorber and Coil Spring Assembly |
| Damping Type | Oil |
| Grade Type | Premium |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598010278 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 58620 Cross References
| Brand | Part Number |
|---|---|
| 58620ST, FULTAF0850RGK | |
| Chrysler | 4684681, 4684681AB, 4684682, 4684682AB, 4684840, 4721340AA, 4737526, 4743127, 4743128, 4743129, 4743224AA, 4743225AA, 4743226AA, 4743227AA, 4743228AA, 4743229AA, 4743230AA, 4743231AA, 4743232AA, 4743233AA, 4743411AB, 4743412, 4743412AB, 4743412AC, 4743413AB, 4743413AC, 4743642, 4743643, 4766124, 4766452AA, 4797641, 4797642, 4897451AA, 5066333AA, 5066334AA, 5066336AA, 5066337AA, 5135538AA |
| Dodge | 4684681, 4684681AB, 4684682, 4684682AB, 4684840, 4721340AA, 4737526, 4743125, 4743127, 4743128, 4743129, 4743224AA, 4743225AA, 4743226AA, 4743227AA, 4743228AA, 4743229AA, 4743230AA, 4743231AA, 4743232AA, 4743233AA, 4743411, 4743411AB, 4743412, 4743412AB, 4743412AC, 4743413AB, 4743413AC, 4743547, 4743642, 4743643, 4743686, 4766124, 4766452AA, 4797640, 4797641, 4797642, 4897451AA, 5066333AA, 5066334AA, 5066336AA, 5066337AA, 5135538AA |
| FCS | SC00026 |
| NAPA Shocks | 58620 |
| Plymouth | 4684681, 4684681AB, 4684682, 4684682AB, 4684840, 4737526, 4743125, 4743127, 4743128, 4743129, 4743411, 4743411AB, 4743412, 4743412AB, 4743412AC, 4743642, 4743643, 4766124, 4797640, 4797641, 4797642, 4897451AA |
MONROE 58620 Fits Vehicles
- Plymouth Voyager (1995-2000)
- Plymouth Grand Voyager (1995-2000)
- Dodge Grand Caravan (1995-2007)
- Dodge Caravan (1995-2007)
- Chrysler Voyager (2000-2003)
- Chrysler Town & Country (1995-2007)
- Chrysler Grand Voyager (2000)
