(888) 312-8812 Login SignupMagnum RV Suspension Shock Absorber
| Lower Mount Code | XP8 |
| Upper Mount Code | S5 |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 10.125 IN |
| Extended Length | 15.625 in |
| Gas Charged | Yes |
| Lower Mount Type | Cross Pin Mount - Open Ended, 5/16" Hole ID (Both Ends) X 3" Pin Length (Hole Center to Center) |
| Parts Pack(s) | P01167 |
| Travel Length | 5.5 in |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Compressed Length | 257.2 MM |
| Extended Length | 396.9 MM |
| Travel Length | 139.7 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
| Lower Mount Type | T-Bar |
| Lower Mount Code | XP8 |
| Upper Mount Code | S5 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598555373 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| 555037MM, 747730158648 | |
| BULLDOG HD SHOCKS | HD1214-0548 |
| Bulldog HD | HD12140548 |
| Dodge | 3837028, 4039724, 4086418, 4131320, 4131321, 4131350, 4364771, 4364772, 4443467, 4443481, 4504317, 4740238, 4740239, 4740242, 4740243, 4740244, 4740248, 4740249, 5011635AB, 5011635AE, 52039383AC, 52106311AC, 52106312AB, 52106312AC, 52106320AB, 52106320AC |
| GABRIEL | G63359 |
| KYB | KG6402, KG5404, 344066, KG5403 |
| NAPA Shocks | 555037 |
