(888) 312-8812 Login SignupMONROE 32288 Monro-Matic Plus Front Suspension Shock Absorber
Tap to view 3 more
$62.56
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MONROE 32288 Part Description
Manufacturer
Product Description
Monro-Matic Plus Front Suspension Shock Absorber
Features & Benefits
- CONSISTENT RIDE -- Velocity Proportional Valving (VPV) technology and all-weather fluid containing special additives to reduce friction and ensure smooth rod reaction and an overall smoother ride
- RELIABLE PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- RESTORES RIDE AND HANDLING -- Larger bore provides more efficient damping control to provide consistency and a smooth ride (where applicable)
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while banded piston and bronze reinforced guide provide durability
- GET MORE MILES FROM YOUR RIDE -- Designed and validated to meet OE spec and deliver consistent performance
MONROE 32288 Specifications
Product Attributes
| Compressed Length | 14.125 IN |
| Compressed Length | 358.8 MM |
| Extended Length | 22.375 in |
| Extended Length | 568.3 MM |
| Travel Length | 8.25 in |
| Travel Length | 209.5 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS26 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL |
| Upper Mount Code | LS26 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598025715 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 32288 Cross References
| Brand | Part Number |
|---|---|
| 32288MM, FT1Z17606A51A | |
| AUTOZONE | MS33-32641B, TS33-32641B, TS33-33491B |
| AutoZone | MS3332641B, TS3332641B, TS3333491B |
| Duralast | TS3332641B |
| Ford | D8TZ18125D, E4TZ18124F, E4TZ18124G, E4TZ18125E, E4TZ18125M, E7TZ18124C, E7TZ18124D, E7TZ18124H, E7TZ18124J, E7TZ18124K, E7TZ18124R, E7TZ18125C, E7TZ18125D, E7TZ18125E, E7TZ18125F, E7TZ18125J, E7TZ18125K, E7TZ18125L, E7TZ18125M, E7XZ18124D, E7XZ18124F, E7XZ18125D, E7XZ18125G, F2TZ18124R, F2TZ18125A, F4TZ18124D, F4TZ18124H, F4TZ18124J, F4TZ18124K, F4TZ18125B, F4TZ18125E, F4TZ18125F, F4TZ18125G, F4TZ18125H, F4TZ18125L, F5TZ18124AA, F5TZ18125AA, F65Z18125DC, F75Z18124AA, F75Z18124BA, F75Z18125AG, F75Z18125DA, F75Z18125DC, F75Z18125HB, F75Z18125HC, F75Z18125JB, F75Z18125PB, F75Z18125PC, F7AZ18124TB, F7AZ18124ZG, F7AZ18125YA, F7AZ18125ZA, F85Z18124LA |
| GABRIEL | 81821, 77455, 61614, 61655, 58455, G63455, G63809 |
| KYB | 344267, KG54320, 565007, KG5456 |
| MasterPro Shocks and Struts | FD132 |
| Monroe Shocks & Struts | 59508 |
| NAPA Proformer | SH81821 |
| NAPA Response | 94153 |
| Sensen | 12140128 |
MONROE 32288 Fits Vehicles
- Ford F-250 HD (1997)
- Ford F-350 (1985-1997)
- Ford F-250 (1987-1996)
