(888) 312-8812 Login SignupMGM BRAKES 1412012 DRUM BRK CHAMBR
$11149
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
MGM BRAKES 1412012 Part Description
Manufacturer
Product Description
Service Chamber
Features & Benefits
- Steel pressure cap
- Heavy gauge steel mounting base
- Heavy-duty nylon reinforced diaphragm
- Mounting studs, grade 5, heat treated/plated
- Low-profile design
- S-Cam and disc brake applications
- Available in 1.75, 2.25, 2.50 and 3.00” stroke
- Available in 1.75, 2.25, 2.50 and 3.00" stroke
Specifications
Production Unit
Mounting Bolt Thread: 7/16-14
Port Size: 3/8-18 NPTF
Threaded Yoke
Stroke (in.): 1.75
Service Size: 12
Spring Size: N/A
Features & Benefits
- Formed Steel Pressure Cap -Epoxy-Coated
- Formed Steel Non-Pressure Chamber -Epoxy-Coated
- Heavy-Duty Nylon Reinforced Diaphragms
- Top and Side Air Ports- 3/8" NPTF
- Center Hole Shield (Except type 12 and type 16)
Technical Data
| Stroke | 1.75" (44.5 mm) |
| Weight lb (kg) | 3.80 lb (1.7 kg) |
| A | 3.84" (97.5 mm) |
| B | 3.13" (79.5 mm) |
| C | 5.69" (144.5 mm) |
| D | 3.00" (76.2 mm) |
Replacement Parts
| Production Unit: | Call Customer Service for available replacement parts. |
MGM BRAKES 1412012 Specifications
Product Attributes
| Chamber Type | Service Chamber |
| Diaphragm Diameter | Rubber IN |
| Mounting Bolt Length | 1.170 IN |
| Mounting Bolt Thread | 7/16-14 |
| Port Size | 3/8-18 NPTF |
| Spring Size | N/A |
| Service Size | 12 |
| Stroke | 1.75 IN |
| Welded Yoke | Threaded Yoke |
| UNIT | Production |
| Diaphragm | Rubber |
| Push Rod Length - with yoke | 10.25 |
| Rod Diameter | 1/2 |
Additional Information
| Country of Origin (Primary) | US |
| 2 | |
| VMRS Code | 013004027 |
