(888) 312-8812 Login SignupMONROE 5648 OESpectrum Suspension Shock Absorber
Tap to view 5 more
MSRP: $167.76
$8099
Save $86.77
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 31
MONROE 5648 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5648 Specifications
Product Attributes
| Lower Mount Code | CLEV |
| Upper Mount Code | S5 |
| Dust Shield Included | No |
| Includes Bump Stop | Yes |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 16.97 IN |
| Extended Length | 23.13 in |
| Gas Charged | Yes |
| Lower Mount Type | Clevis Bracket Mount |
| Parts Pack(s) | P01637,P00590 |
| Travel Length | 6.16 in |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Compressed Length | 431 MM |
| Extended Length | 587.5 MM |
| Travel Length | 156.5 MM |
| Lower Mount Type | Clevis Bracket Mount |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598081568 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5648 Part Interchanges
| Brand | Part Number |
|---|---|
| Lincoln Automotive | 8A5Z18124E, 8A5Z18124F, 8A5Z18124G, 8A5Z18124H, 8A5Z18125A, 8A5Z18125B, 8A5Z18125G, AA5Z18124A, AA5Z18124B, AA5Z18124C, AA5Z18124D, AA5Z18125A, AA5Z18125B, AA5Z18125C, BA5Z18125A, CA5Z18125A, CA5Z18125B, CA5Z18125C |
| Ford | AG1318080AF, AG1Z18124A, AG1Z18124B, AG1Z18124C, AG1Z18124D, AG1Z18124E, AG1Z18124F, AG1Z18124G, AG1Z18124H, AG1Z18125A, AG1Z18125B, AG1Z18125C, AG1Z18125D, CG1Z18125A, CG1Z18125B, CG1Z18125C, CG1Z18125D, DG1Z18124J, DG1Z18124K, DG1Z18124T, DG1Z18124V, DG1Z18125A, DG1Z18125E, 8A5Z18125A, 8A5Z18125B, 8A5Z18125G, AA5Z18125A, AA5Z18125B, AA5Z18125C, BA5Z18125A, CA5Z18125A, CA5Z18125B, CA5Z18125C |
| OEM | AG1Z18125B, AA5Z18125C, CA5Z18125B, 8A5Z18125B, DG1Z18125E, CA5Z18125C, AG1318080AF, BA5Z18125A, AG1Z18125A, DG1Z18125A, AG1Z18125C, AG1Z18125D, CA5Z18125A, 8A5Z18125A, AA5Z18125A, AA5Z18125B, 8A5Z18125G |
| AutoZone | TS34-32552B, TS34-50052B, TS3432552B, TS3450052B |
| Sensen | 3213-0513, 32130513 |
| Unity Automotive | 252130 |
| KYB | 3440037, 349165, 349168 |
| Gabriel | 70096 |
| Motorcraft | ASH1255, ASH23477 |
| Unity | 252130 |
| Autopart International | 2701685245 |
| Lincoln | 8A5Z18125A, 8A5Z18125B, 8A5Z18125G, AA5Z18125A, AA5Z18125B, AA5Z18125C, BA5Z18125A, CA5Z18125A, CA5Z18125B, CA5Z18125C |
| Top Quality | 785648 |
| NAPA Shocks | 5648, NS5648 |
| TRQ | SBA72807 |
| PRT | 932801 |
| PM Auto | PM6001453 |
| FCS | 346131, 346258 |
| Duralast | TS3432552B |
| MasterPro Shocks and Struts | FD180 |
MONROE 5648 Fits Vehicles
- Ford Taurus (2010-2019)
- Lincoln MKS (2009-2012)
MONROE 5648 Cross References
We have 28 alternatives for the 5648 by MONROE:
- 5648ST
- GB5Z17682TCPTM
- OEM AG1Z18125B
- AUTOZONE TS34-32552B
- SENSEN 3213-0513
- UNITY AUTOMOTIVE 252130
- OEM AA5Z18125C
- OEM CA5Z18125B
- OEM 8A5Z18125B
- OEM DG1Z18125E
- OEM CA5Z18125C
- OEM AG1318080AF
- OEM BA5Z18125A
- OEM AG1Z18125A
- AUTOZONE TS34-50052B
- KYB 3440037
- KYB 349165
- OEM DG1Z18125A
- OEM AG1Z18125C
- OEM AG1Z18125D
- OEM CA5Z18125A
- OEM 8A5Z18125A
- GABRIEL 70096
- MOTORCRAFT ASH1255
- OEM AA5Z18125A
- OEM AA5Z18125B
- MOTORCRAFT ASH23477
- OEM 8A5Z18125G
