$58399
Limited availability at this price!
In Stock
VS Air-Sensing Fan Drive
FREIGHTLINER
When the cooling system uses a viscous air-sensing fan drive, Horton Engine Cooling Fan Clutch provides the same type of fan-clutch operation. Its viscous control changes how strongly the fan is coupled instead of using the on-off pneumatic action found on other Horton clutch types. The Horton 9902001 is therefore distinguished by operating method as well as engine fit, which matters when nearby Horton fan-clutch options use different control designs. Restoring the original fan-drive strategy does not require changing the surrounding cooling package simply because another clutch style looks similar.
| Clutch Mounting Surface To Fan Mounting Surface | 2.01 IN |
| FAN PILOT DIAMETER | 6 IN |
| Heavy Duty | 0 |
| MOUNTING BOLT CIRCLE | 5 IN |
| MOUNTING PILOT DIAMETER | 1 IN |
| MOUNTING THREAD TYPE or NUMBER OF HOLES | 2.362204724 |
| OUTER (OVERALL) DIAMETER | 7.48 IN |
| Overall Length | 4.06 IN |
| BELT CONFIGURATION | - |
| BACK PULLEY DIAMETER | - |
| Fan Bolt Circle | 6 |
| CLUTCH TO FAN MOUNTING SURFACE | - |
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (Schedule B) | 8483604040 |
| Harmonized Tariff Code (HTS) | 8483604040 |
| OEM's Part Number | 9802001 |
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Special | 2500 Hours |
| Warranty Special UOM | TX |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| VMRS Code | 042003036 |
| Brand | Part Number |
|---|---|
| BorgWarner | 10025019, 17881-1 |
| Freightliner | 680 200 01 26, 681 200 01 26 |
| KIT MASTERS | 17881-1, RV0122300-00 |
| NAVISTAR | FLT12230000 |
| NAVISTARPFC | FLT12230000 |
