Gates G17213-0808 - Dual Seat Female JIC 37/SAE 45 Flare Swivel - 90 Bent Tube
$19149
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Dual Seat Female JIC 37/SAE 45 Flare Swivel - 90 Bent Tube
Features & Benefits
- Stainless steel couplings last longer than standard couplings so you can avoid replacing an entire assembly before the hose itself needs replacement
- Fortified with 316 grade stainless steel, these longer maintenance intervals mean more value for your dollar.
- Gates Stainless Steel stems are available in the B series for braided hose or the S series for spiral-wire
Product Attributes
| Coupling Description | Stainless Steel Braid Dual Seat Female JIC 37/SAE 45 Flare Swivel - 90 Bent Tube |
| Industrial Description | 8B-8FJSX90M-SS |
| Thread Size | 3/4-16 |
| Inside Diameter | .5 IN |
| Hydraulic Hose Recommendation | Gates EFG3K, G1, G1H, G2, M2T, M3K, M4K, M4KL, M5K, PowerClean |
| Nut Hex Size | .87 IN |
| Drop Length | 1.61 IN |
| Cut-Off Length | 1.4 IN |
| Length | 2.83 IN |
| Inside Diameter | 12.7 MM |
| Nut Hex Size | 22.1 MM |
| Drop Length | 41 MM |
| Cut-Off Length | 35.6 MM |
| Length | 72 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| Country of Origin (Primary) | US |
| UPC | 00770075433118 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
