GATES G20239-1012 Part Description
Manufacturer
Product Description
Female Flat-Face O-Ring Swivel - 90 Bent Tube (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250degF temperature capability for longer assembly life
- +250°F temperature capability for longer assembly life
- +250?F temperature capability for longer assembly life
- +250˚F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
GATES G20239-1012 Specifications
Product Attributes
| Coupling Description | GlobalSpiral Female Flat-Face O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 10GS-12FFORX90S |
| Thread Size | 1 3/16-12 |
| Inside Diameter | .625 IN |
| Hydraulic Hose Recommendation | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Nut Hex Size | 36 MM |
| Drop Length | 1.26 IN |
| Cut-Off Length | 2.94 IN |
| Length | 4.21 IN |
| Inside Diameter | 15.9 MM |
| Drop Length | 32 MM |
| Cut-Off Length | 74.7 MM |
| Length | 106.9 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | US |
| Stock Status | S |
| UPC | 00770075298076 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G20239-1012 Cross References
| Brand | Part Number |
|---|---|
| Aeroquip | 4SA12FRB10 |
| Eaton | 43010U-A32 |
| Goodyear | 29725-1012 |
| N/A | 04030863, M24491-10-12 |
| NAPA | G20239-1012 |
| Parker | 1J971-12-10 |
| Weatherhead | 43010UA32 |
